BK500 - APC Back-UPS UPS

The Back-UPS provides an emergency backup power supply that allows you to shutdown your system in the case of power outages. The Back-UPS automatically switches on and provides high-performance surge protection from electrical noise and power surges.

Questions?
1-888-875-7170
We respond to every email
Part # Description Availability Price Order
BK500 CS 500, 500VA/300W, 120 volt battery backup & surge protector. Includes DSL compatible phone/fax/modem line protection, RS-232 & USB interfaces, USB cable, software & user's manual. Ships Today $119.99
Information:   |  Specifications  |
Accessories:   |  No accessories available  |

BK500 Details

General Information

  • Product Type: Line-interactive UPS
  • Product Series: CS
  • Brand Name: APC
  • Manufacturer: American Power Conversion Corp
  • Product Name: Back-UPS CS 500VA
  • Product Line: Back-UPS

Technical Information

  • Receptacles: 3 x NEMA 5-15R
  • Plug/Connector Type: NEMA 5-15P
  • Cord Length: 6 ft
  • Dataline Protection: RJ-11

Physical Characteristics

  • Height: 6.5"
  • Width: 3.6"
  • Depth: 11.2"
  • Weight (Approximate): 13.80 lb
  • Color: Beige

Interfaces/Ports

  • USB: Yes
  • Serial Port: Yes

Other

  • Package Contents:
    • User Manual
    • Velcro Cord Management Straps Kit
    • CD with software
    • USB cable
    • User Manual
    • Velcro Cord Management Straps Kit
    • CD with software
    • USB cable
  • Green Compliant: Yes
  • Green Compliance Certificate/Authority: ENERGY STAR
  • Certifications & Standards:
    • FCC Part 15 Class B
    • Industry Canada
    • UL 1778
    • cUL Listed
  • Additional Information:
    • Additional Surge Protected Outlets
    • Cord Management
    • Software
    • USB compatible

Power Description

  • Load Capacity (VA): 500 VA
  • Power Consumption: 300 W
  • Input Voltage: 110 V AC
  • Output Voltage: 120 V AC
  • Surge Energy Rating: 480 J
  • Waveform Type: Step Wave

Battery Information

  • Maximum Battery Recharge Time: 8 Hour
  • Backup/Run Time (Half Load): 15 Minute
  • Backup/Run Time (Full Load): 3 Minute
  • Battery Characteristics: Spill-proof, Maintenance-free
  • Battery Chemistry: Sealed Lead Acid

Management

  • Alarm:
    • On Battery
    • Low Battery
    • Overload

Environmental Conditions

  • Temperature: 113°F (45°C)
  • Thermal Dissipation: 24 BTU/h
  • Sound Emission: 45 dB(A)

Controls/Indicators

  • Status Indicators: LED status display with On Line, On Battery, Replace Battery, Site wiring fault and Overload Indicators

Warranty

  • Limited Warranty: 2 Year

The APC BK500 is also known as American Power Conversion APC-BK500 .
