SURT10000XLT - APC Back-UPS UPS

The Back-UPS provides an emergency backup power supply that allows you to shutdown your system in the case of power outages. The Back-UPS automatically switches on and provides high-performance surge protection from electrical noise and power surges.

Part # Description Availability Price Order
SURT10000XLT Smart-UPS RT 10000VA 208V, Ships Today $6,400.00
Information:   |  Specifications  |
Accessories:   |  No accessories available  |

SURT10000XLT Details

General Information

  • Product Type: Dual Conversion Online UPS
  • Product Series: RT
  • Brand Name: APC
  • Manufacturer: American Power Conversion Corp
  • Product Model: SURT10000XLT
  • Product Name: Smart-UPS RT 10000VA 208V UPS
  • Product Line: Smart-UPS

Technical Information

  • Receptacles:
    • 1 x Hard Wire 3-wire 2PH + G - Backup/Surge-protected
    • 2 x NEMA L6-20R - Backup/Surge-protected
    • 2 x NEMA L6-30R - Backup/Surge-protected
  • Plug/Connector Type: Hard Wire 3-wire 2PH + G

Physical Characteristics

  • Height: 10"
  • Width: 17"
  • Depth: 26"
  • Form Factor: 6U Tower
  • Weight (Approximate): 244 lb Net
  • Color: Black

Interfaces/Ports

  • Modular Slots: SmartSlot

Other

  • Package Contents:
    • Smart-UPS RT 10000VA 208V
    • CD with software
    • Service Manual
    • Smart UPS signalling RS-232 cable
    • User Manual
    • Web/SNMP Management Card
    • Smart-UPS RT 10000VA 208V
    • CD with software
    • Service Manual
    • Smart UPS signalling RS-232 cable
    • User Manual
    • Web/SNMP Management Card
  • Certifications & Standards:
    • CSA
    • FCC Part 15 Class A
    • UL 1778
    • UL 1449
  • Additional Information:
    • Supports both Tower and Rack-mountable configurations but does not include rack mounting kit
    • Configurable for 208 or 240 nominal output voltage
    • Scalable runtime
    • Automatic restart of loads after UPS shutdown
    • InfraStruXure Manager Compatible
    • Automatic self-test
    • Frequency and voltage regulation
    • Generator Compatible
    • Input Power Factor Correction

Environmental Conditions

  • Altitude:
    • 0 ft to 10000 ft Operating
    • 0 ft to 50000 ft Storage
  • Humidity:
    • 0 to 95% Relative Humidity Operating
    • 0 to 95% Relative Humidity Storage
  • Temperature:
    • 32°F (0°C) to 104°F (40°C) Operating
    • 5°F (-15°C) to 113°F (45°C) Storage
  • Thermal Dissipation: 2216 BTU/h

Power Description

  • Input Voltage Range:
    • 208 V AC Nominal
    • 160 V AC to 280 V AC Mains Operation
  • Load Capacity: 10 kVA/8 kW
  • Input Voltage: 220 V AC
  • Output Voltage: 208 V AC Nominal
  • Filtering: Full time multi-pole noise filtering, 0.3% IEEE surge let-through, zero clamping response time
  • Frequency:
    • 50 Hz Input
    • 60 Hz Input

Management

  • Network Management: SNMP Manageable
  • Battery Management: Intelligent Battery Management
  • Alarm:
    • On Battery
    • Low Battery
    • Overload
  • Bypass Switch: Automatic
  • Emergency Power OFF: Yes
  • Overload Protection: Resettable circuit breakers

Controls/Indicators

  • Control Panel:
    • On Line
    • On Battery
    • Replace Battery
    • Overload
    • Bypass Indicators

Battery Information

  • Batteries: Spill-proof, Maintenance-free Sealed Lead Acid User Replaceable Hot-swappable
  • Backup/Run Time:
    • 0.22 Hour 4 kW Half Load
    • 0.07 Hour 8 kW Full Load

Warranty

  • Limited Warranty: 2 Year
  • Parts Warranty/Labor: 2 Year

Scalability

  • Power Range: 1 kVA to 10 kVA /

The APC SURT10000XLT is also known as American Power Conversion APC-SURT10000XLT .
