Cisco PIX 500 Series Security Appliances Data Networking
Part #: PIX-501 | SKU: CIS40805

Cisco PIX Security Appliance customers are encouraged to migrate to Cisco ASA 5500 Series Adaptive Security Appliances. Built on the same software foundation as Cisco PIX Security Appliances, the Cisco ASA 5500 Series offers more robust firewall and IPsec VPN capabilities, as well as many additional benefits, including significantly better performance and scalability, Secure Sockets Layer (SSL) VPN support (including clientless, portal-based remote access), advanced Unified Communications (voice/video) security, plus a modular design that allows you to add features such as intrusion prevention (IPS), anti-virus, anti-spam, anti-phishing, and URL filtering.

Cisco PIX 500 Series Security Appliances Data Networking

Part Details: PIX 500 Series Security Appliances, PIX 501 Chassis (Chassis, Software, 1 FE+4 FE Port Switch)

Additional Information

Manufacturer Cisco
Model Name PIX 500 Series Security Appliances

Technical Information

  • Firewall Protection:
    • Denial of Service (DoS)
    • Malformed Packet Attack
    • DNSGuard
    • FloodGuard
    • FragGuard
    • MailGuard
    • IPVerify
    • TCP Intercept

General Information

  • Product Type: Network Security/Firewall Appliance
  • Product Series: 500
  • Brand Name: Cisco
  • Manufacturer: Cisco-IMSourcing
  • Product Model: 501
  • Product Name: PIX 501 Firewall

Physical Characteristics

  • Height: 1"
  • Width: 6.3"
  • Depth: 5.5"
  • Form Factor: Desktop
  • Weight (Approximate): 12 oz

Interfaces/Ports

  • Number of Network (RJ-45) Ports: 5
  • Total Number of Ports: 5
  • Management Port: Yes

Other

  • Certifications & Standards:
    • UL1950
    • CAN/CSA-C22.2 No. 60950-00
    • IEC60950
    • EN60950<br><br> EMC:
    • EN55022 Class B
    • CISPR22 Class B
    • AS/NZS 3548 Class B
    • VCCI Class B
    • EN55024
    • EN50082-1
    • EN61000-3-2
    • EN61000-3-3,
  • Additional Information:
    • Cisco PIX 501 chassis
    • Software
    • The integrated DHCP server supports up to 32 DHCP leases.
    • Virtual Private Networking (VPN)
    • Network Address Translation (NAT)
    • Denial-of-Service (DoS) Attack Prevention
    • Simple, Web-Based Management with PIX Device Manager (PDM)
    • System bus: Single 32-bit, 33-MHz PCI
    • VPN Accelerator Card Plus (VAC+) Support: No
    • Failover Support: No<br><br> Operating:
    • Shock: 250 G, &lt; 2 ms
    • Vibration: 0.41 Grms2 (3-500 Hz) random input<br><br> Nonoperating:
    • Shock: 65 G, 8 ms
    • Vibration: 1.12 Grms2 (3-500 Hz) random input

Network & Communication

  • Network Standard:
    • 10/100Base-TX
    • 10Base-T
  • Ethernet Technology: Ethernet

Power Description

  • Input Voltage:
    • 110 V AC
    • 220 V AC
  • Power Source: Power Supply

Memory

  • Memory Technology: SDRAM
  • Flash Memory: 8 MB
  • Standard Memory: 16 MB

Management & Protocols

  • Manageable: Yes
