Cisco Catalyst 4500 Series Switch Data Networking
Part #: WS-X4248-RJ45V= | SKU: CIS40753

Each Cisco Catalyst 4500 Series chassis model has a different number of available card slots and can accommodate a variety of line card and supervisor options. Customers can choose 48-port 10/100, 10/100/1000 and Power over Ethernet line cards. These cards can be added to the chassis as needed to customize an access, distribution, or server aggregation platform.

Cisco Catalyst 4500 Series Switch Data Networking

Part Details: Catalyst 4500 Series Switch, Catalyst 4500 (PoE 802.3af, 10/100, 48-Ports and RJ45)

Additional Information

Manufacturer Cisco
Model Name Catalyst 4500 Series Switch

General Information

  • Product Type: Switching Module
  • Brand Name: Cisco
  • Manufacturer: Cisco Systems, Inc
  • Product Model: WS-X4248-RJ45V=
  • Product Name: 48-port IEEE 802.3af-compliant PoE Switching Module

Technical Information

  • Application/Usage: Switching Network

Physical Characteristics

  • Dimensions: 1.2" Height x 14.4" Width x 16" Depth

Interfaces/Ports

  • Interfaces/Ports: 48 x 10/100Base-TX LAN
  • Interfaces/Ports Details: 48 x RJ-45 10/100Base-TX LAN

Other

  • Compatibility:
    • Catalyst 4503 Switch
    • Catalyst 4506 Switch
    • Catalyst 4507R Switch
    • Catalyst 4510R Switch
    • Catalyst 4003 Switch
    • Catalyst 4006 Switch
    • Catalyst 4503 Switch
    • Catalyst 4506 Switch
    • Catalyst 4507R Switch
    • Catalyst 4510R Switch
    • Catalyst 4003 Switch
    • Catalyst 4006 Switch
  • System Requirements:
    • One Expansion Slot
    • Minimum Software Requirements:
    • Cisco IOS Software Release: 12.2(18)EW
    • Catalyst OS Version: 8.3(1)GLX
  • Additional Information:
    • To provide PoE with the 48-port PoE 10/100BASE-TX switching module in a Catalyst 4006 switch, you must have a power entry module (PEM) and a power shelf installed
    • Power over Ethernet: Up to 15.4 W per powered device on all 48 ports (to a 312 W total on the Catalyst 4006)
    • Auto MDIX is not supported
    • Power regulation: Internal on the switching module
    • Enterprise and commercial: Designed to power IP phones, wireless base stations, video cameras, and other IEEE-compliant powered devices

Environmental Conditions

  • Altitude: -196.85 ft to 13123.36 ft Operating
  • Humidity: 10% to 90% Non-condensing Relative Humidity

Media & Performance

  • Connectivity Media: UTP 10/100Base-TX
