PD7130-YB-PTRK3 - Datalogic Power Scan PD 7100 Bar code Scanner

The Datalogic Power Scan PD 7100 is a rugged industrial linear imager that offers the highest standards of reliability, robustness and performance plus exceptional value. The unit is 2-meter drop-tested to concrete, IP65 rated against water and dust, and capable of operating in the most extreme temperature conditions. Three year standard warranty ensures low total cost of ownership. The Power Scan PD 7100 features advanced code stitching capabilities, making it easier to read poorly printed and damaged codes the first time. The Power Scan PD 7100 is available with two multiple interfaces, depending on application requirements: industrial applications and harsh environments: RS-232, Wedge, Wand Emulation and USB and for POS checkouts: RS-232, IBM 46xx and USB.

Questions?
1-888-875-7170
We respond to every email
Part # Description Availability Price Order
PD7130-YB-PTRK3 Power Scan PD 7100, PowerScan PD7130 (Wedge Kit, CAB-437 with Pointer) - Color: Yellow/Black
Ships Free in 3-5 Days
$277.98
Retail $503
Save 44%
Information:   |  Datalogic's Power Scan PD 7100 page  |
Accessories:   |  Accessories/Options  |  Datalogic Power Scan PD 7100 service contract  |

PD7130-YB-PTRK3 Details

Technical Information

  • Scan Pattern: Linear
  • Scan Rate: 390 scan/s
  • Connectivity Technology: Cable
  • Light Source: Laser
  • Image Sensor: Imager
  • Barcode Symbology Supported:
    • 1D / Linearcodes:
    • Auto discriminates all standard 1D codes
    • GS1 DataBar linearcodes
    • Postal Codes:
    • China Post
    • Stacked Codes
    • GS1 DataBar Expanded Stacked
    • GS1 DataBar Stacked
    • GS1 DataBar Stacked Omni directional
    • 1D / Linearcodes:
    • Auto discriminates all standard 1D codes
    • GS1 DataBar linearcodes
    • Postal Codes:
    • China Post
    • Stacked Codes
    • GS1 DataBar Expanded Stacked
    • GS1 DataBar Stacked
    • GS1 DataBar Stacked Omni directional
  • Maximum Scan Resolution: 3 mil
  • Depth of Field:
    • 0.60" - 5.50"@5 mil
    • 0 mil - 17.30"@7.50 mil
    • 0 mil - 23.60"@10 mil
    • 0 mil - 31.50"@13 mil
    • 0 mil - 46.90"@20 mil
    • 0.80" - 94.50"@40 mil
    • 2" - 118.20"@55 mil - Reflective
    • 5.10" - 17.39 ft@100 mil - Reflective

General Information

  • Product Type: Handheld Barcode Scanner
  • Brand Name: Datalogic
  • Manufacturer: Datalogic S.p.A
  • Product Model: PD7130
  • Product Name: PowerScan PD7130 Barcode Reader
  • Product Line: PowerScan

Physical Characteristics

  • Height: 8"
  • Width: 3"
  • Depth: 4.5"
  • Color:
    • Black
    • Yellow
  • Weight (Approximate): 9.90 oz

Interfaces/Ports

  • Host Interface: Keyboard Wedge

Other

  • Green Compliant: Yes
  • Green Compliance Certificate/Authority: China RoHS

Warranty

  • Limited Warranty: 3 Year
Part # Description Availability Price Order
TSP-US-SC-3 BCI Service Contracts, True Support Contract 3-year - Scanners Includes Tier 1 and Tier 2 Technical Helpdesk Support 7:30am-cst-5:00pm-cst, RMA Triage, OEM Service Contract management, Pre/post repair inspection and image loading. $48 per year for 3 years, billed annually.
Ships Free in 3-5 Days
$48.00
Q-PD71-3 Datalogic Service Contract - 3 year, PowerScan 7100D, Ease of Care Overnight Replacement Comprehensive
Ships Free in 3-5 Days
$64.00

The Datalogic PD7130-YB-PTRK3 is also known as Data Logic DTL-PD7130-YB-PTRK3 or PD7130YBPTRK3 .
