PRINTING CHARACTERISTICS |
|
|
Resolution:
Print speed (@ 8 lpi):
Characters per inch (cpi):
Characters per line:
Print zone width:
Inserted form:
|
Max. 208 dpi horizontal, 96 dpi
vertical
12 lps min. @ 10 cpl, 6 lps min. @40 cpl
Selectable (defaults = 6 and 8)
Selectable to 30 max.
(defaults=13, 14.8, 17.3 and 20.8)
74 max. (default=44)
2.54 inches (64.5 mm.) up to 3.54 inches
(89.9 mm.) on slip
9 lines @ 6 LPI (12 lines @ 8 LPI)
6” x 2.75” check when inserted vertically:
Front: 51 lines @ 10 CPI rotated print
Back: 30 lines @ 6 LPI (40 lines @ 8 LPI)
|
FEATURES AND BENEFITS
- Simple Snap-In No-Mess Cartridges with Fast-Drying Ink
- Standard Warranty: Two Years (Extended Maintenance Plan
Available)
- PowerPocket® for Protected and Secure Storage of Power
Supply
- Patented Insta-Load® Automatic Paper Loading
- Cash Drawer Drivers: Dual with Status (Single RJ12)
- Font Selections: Small Draft, Medium Draft, Large Draft and
Near Letter Quality
- Selectable Printing Features of Bold, Italics, Size Scaling and
Rotated
- Emulations: Ithaca/IBM, Epson ESC/POS, Epson TM-U325, Microline
(Other Financial Emulations: Contact Us For Details)
- APA and Epson Bit Map Graphics
- Data Buffer: 8K (Adjustable)
- n 208K Non-Volatile Flash for Multiple Character Sets, Bit
Images and EJ
- Bar codes: Code 39, Code 93, Interleaved 2 of 5, UPC-A and
UPC-E, EAN8 and EAN13, Code 128
- 65 Language Character Sets Supported (EURO Character
Included)
- Self-Diagnostics
- Remote Statistics
- Paper Out and Ink Low Detection and Indicators
- Software Developer’s Toolkit Available
- Top Drop-in Forms Insertion with Programmable Top of Form
- Independent Validation
|
PHYSICAL CHARACTERISTIC |
Dimensions without cutter (in
inches):
Dimensions without cutter (in mm.):
Dimensions with cutter (in inches):
Dimensions with cutter (in mm.):
Weight:
Shipping:
|
6.75 W x 9.75 D x 5.92 H
172 W x 248 D x 151 H
6.75 W x 9.75 D x 6.44 H
172 W x 248 D x 164 H
6 lbs. (2.7 Kg)
8 lbs. (3.6 Kg)
|
INTERFACE OPTIONS
RS232C: Bi-Directional Serial (9- or 25-Pin
D-shell)
IEEE1284: Bi-Directional Parallel (25-Pin D-shell or 36-Pin
Centronics)
Universal Serial Bus (USB)
10 Base-T Ethernet
PRINTER DRIVERS
USB, WindowsTM 95/98/2000/Me/XP, XFS 2.0
compliance is available, OPOS, Vista
POWER REQUIREMENTS
Small power brick internally mounted in
PowerPocket® slot: 100-240 VAC Universal Switcher, 47-63 HZ OR 24
VDC from external power source
RELIABILITY
Printer in full operation (tear-bar
model)*
MTBF: 28,000 hours
Auto-Cutter: 1,000,000 cuts
*Reliability data is based on Ithaca standard test conditions
simulating a
normal operating environment.
|
ENVIRONMENTAL SPECS |
Extended Operating Temperature:
Storage Temperature:
|
32 to +113 °F @ 10 to 90% RH,
0 to +45 °C
14 to +140 °F @ 10 to 90% RH,
-10 to +60 °C
|
REGULATORY COMPLIANCE
FCC Class A UL/ULc CE Mark TUV
RoHS
WHO WE ARE
TransAct Technologies Incorporated
(Nasdaq:TACT) is the leader in developing and manufacturing
market-specific printers for transactionbased industries. These
industries include gaming, lottery, POS, kiosk, and banking. Each
individual market has distinct, critical requirements for printing
and the transaction isn’t complete until the receipt and/or ticket
is produced. TransAct printers are designed from the ground up
based on market specific requirements and are sold under the
Ithaca® and Epic product brands. TransAct distributes its products
through OEMs, valueadded resellers, and selected distributors.
TransAct has over two million printers installed around the world.
TransAct has a strong focus on the after-market side of the
business, with a high commitment to printer service, supplies, and
spare parts. TransAct is headquartered in Hamden, CT. For more
information on TransAct, visit www.transact-tech.com or call
203-859-6800. |
MEDIA |
- Paper roll (one ply: for best results,
use TMP or Recycled):
3 inches (76 mm.) W, 4.0 inches (100 mm.) in diameter
- Paper roll thickness: .003 in. to .004
in. (.076 mm. to .102 mm.)
- Inserted form thickness (one-ply): .003
in. to .0047 in.
(.076 mm. to .119 mm.)
- Form dimensions for validation (in
inches): Minimum 2.75 W x 2.75 L,
Maximum 11 W x 8.5 L
- Form dimensions for validation (in mm.):
Minimum 70 W x 70 L,
Maximum 279 W x 216 L
- Form dimensions for full check print
inserted vertically (in inches):
Minimum 2.75 W x 6 L, Maximum 2.75 W x 8.75 L
- Form dimensions for full check print
inserted vertically (in mm.):
Minimum 70 W x 152.4 L, Maximum 70 W x 152.4 L, Maximum
70 W x 222.3 L
|
PRINT CARTRIDGES**
Black, red, green, blue: Average 7 million
characters to ink depletion (avg. 16 dots/character) **Reliability
data is based on HP test, results.
|
