Janam XM2 RFID Reader

Fully-featured to provide the power and performance required for all-day, every-day use by mobile workers in freight and rail operations, the XM2-RFID for Rail is specially-designed to read the Automatic Equipment Identification (AEI) RFID tags required on all railcars in North America and widely used globally, allowing rail and intermodal companies to track and monitor equipment effectively. The XM2-RFID for Rail is equipped with a user-addressable compass for integration with transportation applications, brilliant 3.2-inch color display, Motorola SE4500 2D imager for robust decoding of the hardest-to-read barcodes and support for Microsoft’s Windows Embedded Handheld 6.5 operating system.
Questions?
1-888-875-7170
We respond to every email

Frequency ?

Style ?

Operating System ?

Interface

RAM Memory

XM2 Options
Part # DescriptionAvailabilityPriceOrder
XM20W-0NRLCK1 XM2-RFID, AEI Rail/Road RFID Reader, Wi-Fi (802.11 b/g), Bluetooth, Windows Embedded Handheld, 128MB /128MB, No Scanner, Digital Compass, Numeric Keypad. Includes battery and USB cradle.
Ships Free in 3-5 Days
$1,095.90
Retail $1895
Save 42%
XM20W-FNRLCK1 XM2-RFID, AEI Rail/Road RFID Reader, Wi-Fi (802.11 b/g), Bluetooth, Windows Embedded Handheld, 128MB /128MB, SE4500 2D Imager, Digital Compass, Numeric Keypad. Includes battery and USB cradle. Ships Free Today $1,186.05
Retail $2125
Save 44%

Janam XM2 Details

TECHNICAL

Operating System

Microsoft Windows Embedded Handheld 6.5

Processor

Freescale ARM 9 processor

Memory

128MB RAM / 128MB NAND Flash, Optional 256MB RAM / 256MB Flash

Expansion

User-accessible microSD card slot

Power

2880mAh hot-swappable Li-ion battery

PHYSICAL

Dimensions

5.8” H x 2.9” W x 1.0” L /148mm H x 73mm W x 25.4mm L

Weight

13oz / 370g including battery

 Keypad Numeric

Display

3.2 inch QVGA with LED backlight

Touch Panel

Resistive touch screen

ENVIRONMENTAL

Operating Temperature

-4º to 122º F / -20º to 50º C

Storage Temperature

-22º to 158º F / -30º to 70º C

Humidity

5% to 90% RH (no condensation)

Drop

4ft / 1.2m drop to concrete on four sides

Water & Dust

IP64

Tumble

250 3.2' tumbles (250 drops)

Electro Static Discharge (ESD)

+/- 15kVdc air; +/- 8kVdc contact

Sterilization

75.9% to 81.4% concentration alcohol rub

INTERFACE FEATURES

Audio

Speaker and Microphone

Alerts

Vibration; LED indicators; audio beep

Communication Port

Industrial connector

LED Indicators Tri-color

Scan Triggers

Left, right, center buttons

DATA CAPTURE

Imager

Motorola SE4500 1D/2D CMOS

RFID Reads industry-standard Automatic Equipment Identification (AEI) RFID tags

WIRELESS COMMUNICATION

WLAN

802.11b/g/n

Security

WEP (40 or 128 bit); TKIP; AES; WPA2-PSK; WPA-PSK; WPA2 (EAP-TLS, EAP-PEAP)

WPAN

Bluetooth v2.1 with EDR

MOBILE APPURTENANCES

Compass

API-addressable compass for applications

ACCESSORIES

Single-slot USB/Serial cradle kit

Cradle Cup kit

The Janam XM2 is also known as the Janam Technologies LLC XM2 .
