Microscan Quadrus EZ Accessories

Cables, Power Supplies, Mounting accessories, Software, and Manuals
Questions?
1-888-875-7170
We respond to every email

Type

Quadrus EZ Accessories
Part # DescriptionAvailabilityPriceOrder
97-000012-02 Power supply (100-240 VAC, +24VDC, track 3Pin, USA/Euro Plug)
Ships Free in 24-48 Hours
$152.00
20-610024-01 Trigger Connector, 4-pin Plug (screw terminal and field wireable) (self wiring)
Ships Free in 24-48 Hours
$33.00
98-000037-01 Mounting Arm Extension Kit, 6", all readers
Ships Free in 24-48 Hours
$61.00
61-000034-02 Cable, Comm/Serial, 25pin Socket to 9pin Socket, 6 ft
Ships Free in 24-48 Hours
$30.00
98-000046-01 Large Base Plate, 12"x12"
Ships Free in 24-48 Hours
$44.00
20-610020-01 Pwr Conn, 3pin Sckt (screw term and field wireable for custom wiring into IB-131)
Ships Free in 24-48 Hours
$33.00
20-500013-01 BOX, INTERFACE, DEVICENET, Brand Label
Ships Free in 24-48 Hours
$655.00
FIS-0001-0025 Keyboard wedge (must order wedge-PC cable separately) Check Availability Call for Details
99-440002-03 Package detector with connector See Replacement Call for Details
99-000009-01 Interface Box, IB-151, Ethernet & USB Check Availability Call for Details
98-000096-01 Kit, Monitor 7" TFT LCD and Video I/O Cable, 10 feet Check Availability Call for Details
98-000040-01 Interface Box Kit, IB-150 & Quadrus EZ Cable Check Availability Call for Details
98-000039-01 Kit, IB-152, DB-25 Plug Terminal Block, DB25 Gender Changer, Works with IB-131 Check Availability Call for Details
98-000037-02 Extension Kit, All Scanners, 4 inch Check Availability Call for Details
98-000036-01 Kit, Right Angle-Up Mirror Check Availability Call for Details
98-000020-02 Mounting Arm/Adapter Kit, Quadrus/EZ, 4 inch Check Availability Call for Details
98-000020-01 Mounting Arm/Adapter Kit, Quadrus/EZ, 6 inch Check Availability Call for Details
97-100004-15 MS-Connect 210 Accessories, Power supply, 110 VAC, 24VDC, USA plug with Microchange. See Replacement Call for Details
97-100004-12 Power supply, 220 VAC, 24VDC, EURO plug with Microchange See Replacement Call for Details
97-100004-11 Power supply, 110 VAC, 24VDC, USA plug with Microchange See Replacement Call for Details
83-006700 User Manual, Hard Copy Check Availability Call for Details
61-330006-01 Cable, DeviceNet Box to Scanner, 6 foot Check Availability Call for Details
61-100030-02 IB-131 multidrop cable, 10-ft Check Availability Call for Details
61-100029-01 IB-131 daisy chain cable, 1-ft Check Availability Call for Details
61-000034-01 Cable, Communications, DB-25 Socket to DB-9 Socket See Replacement Call for Details
61-000033-01 Cable, Video I/O Check Availability Call for Details
37-000001-01 MS-Connect 210 Accessories, TOOLS CD, User's Manuals, ESP Software Check Availability Call for Details
20-570006-35 Wedge to PC cable for IBM XT/AT keyboards Check Availability Call for Details
20-570006-34 Wedge to PC cable for IBM PS/2 keyboards Check Availability Call for Details

Microscan Quadrus EZ Accessories Details

IB-880 Interface Box The IB-880 Interface Box is an optional wiring accessory for the MS-880 scanner. The interface box is easy to wire, and makes switching scanners on the line as easy as removing only 4 standard screws. Using the IB-880 allows external devices such as light stacks, hand held scanners or stop-line devices, to be connected and controlled by the scanner. Download Specifications

IB-105 The IB-105 (interface box), available in five options, is a junction that provides connectivity between the MS-710 scanner, the host or LAN, power input, and trigger devices. The box has an internal relay contact (1 watt), a new master pin button to allow input of master label data, a default switch, a power switch, and a mode switch to toggle between RS-232 and RS-422 or 485 (depending on option). Download Specifications

IB-131 The IB-131 interface box simplifies scanner connection for the MS-911 and MS-820 scanners by providing a direct 10-28V connection to the host, power supply, and external triggering device. The IB-131 may be used in single drop, multidrop, or daisy chain configurations. Download Specifications

Keyboard Wedge The wedge allows you to bypass the usual RS-232 port connection and input scanned data to a host via the keyboard line. It is physically inserted between the keyboard, scanner, and host. Scanned data appears to the host as if it were typed in from the keyboard. The wedge is ideal for automated manufacturing and office applications where bar code input is easier and quicker than typing. Download User Manual

Power Packs The Microscan Power Packs are used to power Microscan equipment. The Power Packs are available in seven different configurations.

Object Detector The Microscan Object Detector Kit includes an infrared photo detector complete with cable, connector, mounting bracket, and screws. When installed and connected to a Microscan scanner or decoder, it is used to detect objects within its range and send triggers that initiate read cycles.

Adapter Box The Adapter Box (ADP) is a junction that provides connectivity between the MS-3 scanner, the host or LAN, power input, and trigger devices. The Adapter Box is also compatible with the MS-610.

Mounting Plates The Microscan scanner mounting plates are designed for the easy attachment of scanners in your particular application. The mounting plates are a flat attachment with pre-drilled holes that align with specified scanners. Mounting plate kits include required mounting hardware.

Auxiliary Lighting In many bar code applications, such as automotive, aerospace, and electronics, auxiliary lighting can be helpful, or even essential for increasing contrast and readability of symbols. Each light has different illumination characteristics which suit them to different application requirements. All of the lights offered here are made to industrial-grade standards to withstand wear and tear, dust, and other harsh environmental conditions. Download Specifications

Mounting Arms The Microscan mounting arm is a robust device for mounting unattended bar code scanners in virtually any environment, including industrial applications. The arm is made of marine-grade powder-coated aluminum. The ball (which forms the joint) is made of injection-molded rubber, which grips the mount firmly in place and minimizes any movement or vibration to the scanner. Mounting arms can be rotated almost any direction, allowing for flexible positioning of your bar code scanner. Download Specifications

Right Angle Mirrors Right angle beam projection is available for the MS-520, MS-610, and MS-710 scanners. This accessory is useful where alternative mounting is necessary, particularly in tight places and where a wider scan width is required at shorter ranges.

The Microscan Quadrus EZ Accessories is also known as the Microscan Systems Quadrus EZ Accessories .
