Motorola AP 7532 Access Point

Finally - maximum 802.11ac speed at an affordable price point. Now you can deliver dependable blazing desktop-style wireless speed to all your users on all their devices and all their applications with the AP 7532 access point. You get a comprehensive feature set, 3X3 MIMO and high-powered radios that mean you"ll need fewer access points, driving costs down even further. And with its sleek, understated look, the internal antenna version of the AP 7532 is at home anywhere in your environment "" including customer-facing public spaces.
Questions?
1-888-875-7170
We respond to every email

Power

Mesh

Radio Count

Wireless Type

MIMO

Antenna

Data Transfer Rate

Environment

AP 7532 Options
Part # DescriptionAvailabilityPriceOrder
AP-7532-67030-US AP 7532, Dual Radio, 802.11ac, 3x3, Internal Antenna, US Ships Free Today $612.15
AP-7532-67030-WR AP 7532, Dual Radio, 802.11ac, 3x3, Internal Antenna, WR Ships Free Today $612.15
AP-7532-67040-US AP 7532, Dual Radio, 802.11ac, 3x3:, External Antenna (Sold Separately), US
Ships Free in 3-5 Days
$612.15
AP-7532-67040-WR AP 7532, Dual Radio, 802.11ac 3x3, External Antenna (Sold Separately), WR Ships Free Today $612.15

Motorola AP 7532 Details

ANTENNA SPECIFICATIONS

Connector type

Three RP SMAs (External only - AP-7532-67040-xx)

PHYSICAL CHARACTERISTICS

Housing

Plenum-rated housing (UL2043)

LEDs

2 top-mounted LEDs; activity indication

Weight

1.8 lbs / 0.82 kg

Dimensions (HxWxD)

1.6 in. H x 6.5 in. W x 7.1 in. L / 41 mm H x 165 mm W x 180 mm L

POWER SPECIFICATIONS

Integrated power over ethernet support

802.3af

Operating current

312 mA at 48 V

Operating voltage

48v

RADIO SPECIFICATIONS AND NETWORKING

Operating channels

2.4 GHz band: channel 1 through channel 13 5.2 GHz band: channel 36 through channel 165 * Channel availability depends on local regulatory restriction

QoS

WMM, WMM-UAPSD, 802.1p, Diffserv and TOS

Data rates supported

802.11b/g: 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48 and 54 Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps 802.11n: MCS 0-23 up to 450 Mbps; Turbo mode (256 QAM) on 2.4 GHz band up to 600 Mbps 802.11ac: MCS 0-9 up to 1.3 Gbps

Security

Stateful Firewall, IP filtering, NAT, 802.1x, 802.11i, WPA2, WPA Triple-Methodology Rogue Detection: 24x7 dual-band WIPS sensing, on-board IDS and secure guest access (hotspot)

Frequency

2412 to 2484 MHz, 5180 to 5850 MHz

Layer 2 and Layer 3

Layer 3 routing, 802.1q, DynDNS, DHCP server/client, BOOTP client, PPPoE and LLDP

Wireless medium

Direct Sequence Spread Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM) and Spatial Multiplexing (MIMO)

Transmit power adjustment

1dB increment

REGULATORY SPECIFICATIONS

Electrical safety

UL 60950-1, EN 60950-1, IEC 60950-1, UL2043, cUL 60950-1, RoHS

Radio approval

FCC (USA), EU, TELEC

USER ENVIRONMENT

Electrostatic discharge

15kV air, 8kV contact (Internal AP-7532-67030-xx) 12kV air, 6kV contact (External AP-7532-67040-xx)

Operating humidity

85% RH non-condensing

Operating temperature

Internal antennas: 32° F to 104° F/0° C to 40° C External antennas: -4° F to 104° F/-20° C to 40° C

Storage temperature

-40° F to 158° F / -40° C to 70° C
