- 8MP auto-focus camera for 1D/2D barcode scanning and image capture
- Consumer styling with real business durability
- Ultra-strong Gorilla Glass display
- Dual core 1GHz processor plus graphics accelerator
- Standard 802.11a/b/g/n connectivity supports the fastest Wi-Fi networks for superior performance in your facility
- Dual user-selectable data-only modem provides the flexibility to activate the ET1 on the high-speed 4G HSPA+ or 3G EVDO/CDMA networks
- Bluetooth 2.1 with EDR
- Easily build applications that run on the ET1 and other Motorola mobile computers with Motorola"s RhoMobile Suit
- Built for multiple users with feature-level control so each worker is automatically granted access to their own personalized workspace
Consumer styling with real business durability
On the outside, the ET1 is every bit as elegant as today’s most
popular tablets. Yet the ET1 is built for everyday use, able to
handle drops, spills, chilly winter temperatures, extreme heat and
more. And since the display is built with ultra-strong Gorilla®
Glass, it is virtually impervious to damage, able to flex when
dropped without shattering or scratching.
Use anywhere — from retail to field sales and service with
high-speed cellular/Wi-Fi wireless connections
Inside the four walls, support for 802.11a/b/g/n supports the
fastest Wi-Fi networks for superior performance in your facility.
And with a dual user-selectable data-only modem, you get the
flexibility to activate the ET1 on the high-speed 4G HSPA+
worldwide network, the 3G EVDO/CDMA network — or both.* (* Requires
activation and data plans on both networks.)
Secure your data — period
Whether your data resides on the internal drive or on removable
media, it is encrypted, safe from hackers. So you can easily secure
sensitive information, such as credit card data and patient
information, to help comply with industry and government
regulations.
Easily build applications that run on the ET1 — and your other
Zebra mobile computers
The more operating systems you have, the more complex and
expensive application development and maintenance can be. But with
Zebra's RhoMobile Suite, you can easily create a single application
that looks, feels and acts the same on Zebra mobile computers,
regardless of whether it is built on the Android, Microsoft Windows
Mobile or Windows CE operating system, reducing application
development and support costs.
Built for multiple users with feature-level control
With multi-user log-on, each worker is automatically granted
access to their own personalized workspace — the right applications
and device features. And since managers know who is using the
device at any time, task management is easier.
COMMUNICATIONS
WLAN
WPAN
- Bluetooth 2.1 with EDR, Integrated antenna
GPS
- WWAN: Autonomous GPS with Assisted GPS (A-GPS), WLAN:
Autonomous GPS
WWAN
- Dual user-selectable data-only modem; works on 4G/HSPA+
carriers worldwide or 3G/EVDO on CDMA carriers
DATA CAPTURE SPECIFICATIONS
Front camera
- Optimized for video collaboration and low lighting
conditions
Video
Rear camera
- For barcode scanning and image capture: 8MP auto-focus camera
with user-controllable LED flash, illumination and aiming; captures
1D and 2D barcodes, photographs, video, signatures and
documents
PERFORMANCE CHARACTERISTICS
CPU
- OMAP4 dual-core 1 GHz x2 +DSP
Memory
- 1GB RA M,4GB Flash plus 4GB microSD (total of 8GB flash
memory); user accessible microSD card slot (supports up to
32GB)
Operating system
PHYSICAL CHARACTERISTICS
Dimensions
- 5.14 in. H x 0.98 in. D x 8.82 in. W (130.5 mm H x 25.0 mm D x
224.0 mm W)
Weight
- WLAN: 1.4 lbs./0.63 kg
- WWAN: 1.45 lbs./0.66 kg
Keypad options
Display
- 7 in. capacitive; 1024 x 600; 350 NIT; Corning® Gorilla® Glass;
30% thicker than most consumer displays; recessed to provide extra
shock protection
Touch panel
Backlight
Connectivity
- Two USB interfaces: 1 USB 2.0 OTG connector (docking connector)
and 1 USB 2.0 Host connector (expansion module port); HDMI out;
communication via cradle and expansion ports; USB 2.0 host via
expansion module
Expansion modules
- Integrated expansion port for ‘snap-in’ peripherals for Zebra
and third-party peripherals
Expansion capabilities
- User-accessible Micro SDHC card slot (up to 32GB), Expansion
module port
POWER CHARACTERISTICS
Battery
- WLAN: 4620 mAH rechargeable Smart Li-Ion; user replaceable;
rapid resume
- WWAN: 5640 mAH rechargeable Smart Li-Ion; user replaceable;
rapid resume
REGULATORY SPECIFICATIONS
WLAN/Bluetooth
- EN 301 893, EN 300 328, FCC Part 15.247, 15.205, 15.209,
15.203, 15.407, 15.207, RSS-210, FCC Subpart E
EMI/RFI (WLAN)
- EN 301 489-1 & 17, FCC Part 15 Subpart B, ICES-003 Class B, EN
55022, EN 301 489-1 & 3, EN 55024
Electrical safety (WLAN)
- EN 60950-1, 2nd ed., UL / CSA 60950-1, 2nd ed., IEC 60950-1,
2nd ed.
LED safety (WLAN)
- IEC/EN 60825-1, IEC/EN 62471
RF exposure (WLAN)
- EN 62311, OET Bulletin 65 Supplement ‘C’, EN 50371, FCC 47CFR
Part 1.1307(b), Part 2.1093
WWAN/Bluetooth
- EN 301 893, EN 301 908-1 & -2, EN 300 440, EN 300 328, FCC Part
22, 24, 27, 15.247, 15.205, 15.209, 15.203, 15.407, 15.207, EN 301
511, RSS-210, -310, -132, -133 & 139
EMI/RFI (WWAN)
- EN 301 489-1, -3, -7, -17 & -24, EN 55024, ICES-003 Class B,
FCC Part 15 Subpart B, EN 55022, IEC/EN 60601-1-2
Electrical safety (WWAN)
- IEC60950-1, 2nd ed., UL / CSA 60950-1, 2nd ed., EN60950-1, 2nd
ed.
LED safety (WWAN)
- IEC/EN 62471, IEC/EN 60825-1
RF exposure (WWAN)
- OET Bulletin 65 Supplement C, FCC 47CFR Part 1.1307(b), Part
2.1093, EN 62479, EN 62311, EN 62209-2, RSS-102
USER ENVIRONMENT
Operating temperature
- 32° to 122° F /0° to 50° C
Storage temperature
- -4° F to 158° F /-20° C to 70° C
Environmental sealing
Drop specifications
- Multiple 4 ft./1.2 m drop per MIL STD 810G
