Photo of Motorola DS9208-SR4NNK01A
Watch Product Video
View larger image Motorola logo

Motorola DS 9208

PS/2 Kit, 2D Imager. Includes PS/2 cable and power supply. Color: Black


Free Shipping

Ships Today


Motorola DS 9208 Scanner

The Motorola DS 9208 general purpose presentation scanner delivers the blazing speed typical of laser scanners on both 1D and 2D bar codes, accommodating 2D bar codes without sacrificing scanning quality or performance. Users never need to take time to align the bar code with the scanner or pause between scans. Since the DS 9208 can scan bar codes printed on paper labels or on mobile phone displays, users can drive revenue by attracting the millions of customers who are using their cell phones to better manage their lives. Retailers can accommodate customers who download mobile coupons, mobile loyalty cards and more. Quick service restaurants can accept mobile coupons at the register. Hotels can allow guests to use electronic loyalty cards stored on their cell phones, eliminating the need to carry physical cards. And since theaters, theme parks and stadiums can scan mobile tickets as easily as a paper ticket, they can offer customers an added convenience: paperless ticketing.

Full specifications (PDF)

Manufacturer part number: DS9208-SR4NNK01A

Technical Information

  • Scan Pattern: Omni-directional
  • Connectivity Technology: Cable
  • Image Sensor: Imager
  • Depth of Field:
    • 0 mil - 4.50"@5 mil - Code 39
    • 0 mil - 8.50"@10 mil - UPC/EAN
    • 0 mil - 10.50"@13 mil - UPC/EAN
    • 0 mil - 3.80"@6.60 mil - PDF417
    • 0 mil - 4.70"@10 mil - Datamatrix

General Information

  • Product Type: Desktop Barcode Scanner
  • Brand Name: Motorola
  • Manufacturer: Motorola, Inc
  • Product Model: DS9208
  • Product Name: DS9208 Omnidirectional Hands-free Presentation Imager

Physical Characteristics

  • Height: 5.5"
  • Width: 3.2"
  • Depth: 3.2"
  • Color: Twilight Black
  • Weight (Approximate): 10.02 oz


  • Host Interface: Keyboard Wedge


  • Green Compliant: Yes
  • Green Compliance Certificate/Authority: RoHS


  • Limited Warranty: 3 Year
