MT2090-DP4D62170WR - Motorola MT 2000 Series: MT 2090 Hand Held Computer

The Motorola MT 2000 Series: MT 2090 represents another industry first from Motorola - the marriage of the simplicity of a scanner with the brainpower of a mobile computer and an ultra-ergonomic gun-style form factor. The result is a handheld mobile terminal, a highly flexible device capable of streamlining many scan-intensive business processes in a wide variety of industries - from the front to back door in manufacturing plants, retail establishments, warehouses, hospitals and more. The easy-to-use affordable mobile terminal offers a unique hybrid design, able to function as both a scanner and a mobile computer throughout the business day. The MT 2000 Series: MT 2090 can be utilized right out of the box as a scanner - either tethered to a point of sale (POS), laptop or other computing system - or as a standalone wireless mobile computer capable of enabling inventory and other scan-intensive applications anywhere in the enterprise.

We respond to every email
Part # Description Availability Price Order
MT2090-DP4D62170WR MT 2000 Series: MT 2090, SCANNER ONLY. 2D Imager, Direct Park Mark (DPM) Capable, Wi-Fi/Bluetooth, Windows CE 5.0, Numeric Keypad, Color Screen. Does not include necessary cables or accessories. Use either RS-232 cable (Part# CBA-R12-S07PAR) or USB cable (Part# CBA-U12-S07PAR) plus 12v PS (Part# PWRS-14000-148R) for tethered mode for this configuration.
Ships Free in 3-5 Days

MT2090-DP4D62170WR Details

Technical Information

  • Connectivity Technology: Wireless
  • Image Sensor: Imager
  • Electrostatic Discharge (ESD):
    • +/-15 kV DC Air Discharge
    • +/-8 kV DC Direct Discharge
    • +/-8 kV DC Indirect Discharge
  • Drop Specification: 72" To Concrete @ -4°F (-20°C) to 122°F (50°C)

General Information

  • Product Type: Handheld Terminal
  • Product Series: MT2000
  • Brand Name: Motorola
  • Manufacturer: Motorola, Inc
  • Product Model: MT2090
  • Product Name: MT2090 Handheld Terminal

Physical Characteristics

  • Height: 7.8"
  • Width: 3.1"
  • Depth: 5"
  • Weight (Approximate): 13.50 oz


  • USB: Yes
  • Serial: Yes


  • Green Compliant: Yes
  • Green Compliance Certificate/Authority: RoHS
  • Certifications & Standards:
    • IP54
    • FIPS 140-2
    • Electrical Safety:
    • Certified to UL60950-1
    • CSA C22.2 No. 60950-1
    • EN60950-1
    • EMI/RFI:
    • FCC Part 2 (SAR)
    • FCC Part 15 Subpart B - Class B
    • RSS210
    • EN 301-489-1, 489-17
    • Laser Safety:
    • IEC Class 2
    • FDA Class II in Accordance with IEC60825-1
    • EN60825-1

Network & Communication

  • Bluetooth: Yes
  • Wireless LAN: Yes
  • Antenna Form Factor: Internal
  • Wireless LAN Standard: IEEE 802.11a/b/g

Processor & Chipset

  • Processor Manufacturer: Intel
  • Processor Speed: 312 MHz
  • Processor Type: XScale PXA270

Display & Graphics

  • Screen Mode: QVGA
  • Display Color: Color
  • Screen Resolution: 320 x 240


  • Keyboard Type: Numeric
  • Number of Keys: 21


  • Flash Memory: 64 MB
  • Standard Memory: 64 MB

Battery Information

  • Battery Capacity: 2400 mAh
  • Battery Chemistry: Lithium Ion (Li-Ion)


  • Operating System: Windows CE 5.0


  • Limited Warranty: 3 Year
Part # Description Availability Price Order
TSP-US-MC-3 BCI Service Contracts, True Support contract 3-year - Mobile Computers Includes Tier 1 and Tier 2 Technical Helpdesk Support 7: 30am-cst-5: 00pm-cst, RMA Triage, OEM Service Contract management, Pre/post repair inspection and image loading. $60 per year for 3 years, billed annually.
Ships Free in 3-5 Days
SSE-MT20XX-30 Symbol Service Contract - 3 year, Zebra OneCare Essential. Includes Comprehensive coverage, MCL Client & Link Lite Software Support. Includes coverage for cradles.
Ships Free in 3-5 Days
Retail $185.90
Save 23%

The Motorola MT2090-DP4D62170WR is also known as MOT-MT2090DP4D621701 or MT2090DP4D62170WR .
