TT4M2-0101-00 - Printronix T4M Bar code Printer

The T4M provides uncompromised performance and features with the same PSA3 advanced electronic architecture found in the high performance T5000r. Ideal for light industrial and commercial applications, the T4M thermal barcode printer delivers reliable performance with its rugged metal design. Replace other printer brand environments seamlessly with the T4M using the widest breadth of embedded printer protocol interpreters. The T4M maximizes productivity and offers flexibility to grow with changing requirements.

Questions?
1-888-875-7170
We respond to every email
Part # Description Availability Price Order
TT4M2-0101-00 T4M, Thermal transfer printing, 203 dpi, 4" print width, US Kit and Ethernet interface. Ships Free Today $1,271.25
Why don't we show the price?
Information:   |  Download Printronix T4M driver  |  Specifications  |  Printronix's T4M page  |
Accessories:   |  Accessories/Options  |  Bar code Software  |  Printronix T4M service contract  |
Supplies:   |  Printronix T4M Label  |  Printronix T4M Ribbon  |  Printronix T4M Print head  |

TT4M2-0101-00 Details

Technical Information

  • Maximum Mono Print Speed: 10 in/s
  • Maximum Print Resolution: 203 dpi
  • Print Color: Monochrome
  • Maximum Print Width: 4.10"
  • Recommended Use: Label Print
  • Barcode Symbology Supported:
    • Australia Post
    • Aztec Code
    • BC412
    • Code 128-A
    • Code 128-B
    • Code 128-C
    • Code 35
    • Code 39
    • Code 93
    • Codabar
    • NW-7
    • Data Matrix
    • EAN/JAN-8
    • EAN/JAN-13
    • FIM
    • 125 German
    • Industrial 2 of 5
    • ITF-14
    • Matrix 25
    • Maxi Code
    • MSI
    • PDF-417
    • Planet Code
    • Plessey
    • PostBar
    • POSTNET
    • ROYALBAR
    • RSS-14
    • Telepen
    • UCC/EAN 128
    • UPC-A
    • UPC-E
    • UPC-E0
    • UPC-E1
    • UPCSHIP
    • UPS11

General Information

  • Product Type: Direct Thermal/Thermal Transfer Printer
  • Brand Name: Printronix
  • Manufacturer: Printronix, Inc
  • Product Model: T4M
  • Product Name: T4M Thermal Label printer
  • Product Line: ThermaLine

Physical Characteristics

  • Height: 12.1"
  • Width: 11.8"
  • Depth: 18.8"

Other

  • Platform Supported: PC
  • Certifications & Standards:
    • FCC-B
    • ICES-003
    • EN 55022
    • EN 55024
    • EN 61000-3-2
    • EN 61000-3-3
    • EN 60950
    • cMETus
    • CE
    • BSMI
    • CCC
    • C-Tick
    • GOST-R
    • MIC
    • Argentina S mark
  • Additional Information:
    • Snap-in and upgradeable printhead
    • PrintNet Enterprise remote management
    • Media Counter and Ribbon Life Indicator
    • Adjustable transmissive sensor with auto-calibration
    • Large graphic user interface and color coded user cues
    • XML enabled printing and XML based remote management via PXML

Media Types & Handling

  • Maximum Label Width: 5.15"
  • Maximum Label Length: 99"
  • Media Type:
    • Label
    • Film
    • Synthetic Media
    • Tag
    • Ticket Stock
  • Media Size: Custom Size - 5"
  • Media Sensor:
    • Transmissive Media Sensor
    • Reflective Media Sensor
  • Label Core Size: 3"
  • Ribbon Core Size: 1"
  • Maximum Roll Diameter: 8"

Power Description

  • Input Voltage:
    • 110 V AC
    • 220 V AC

Memory

  • Standard Memory: 32 MB
  • Memory Technology: DRAM
  • Flash Memory: 8 MB

Network & Communication

  • Ethernet: Yes
  • Ethernet Technology: Ethernet

Warranty

  • Limited Warranty: 1 Year

Fonts & Emulation

  • Language Emulation: PGL
Part # Description Availability Price Order
178246-004 Printronix Label, 4" x 6" Paper label. 1,000 labels/roll, 4 roll case.
Ships in 3-5 Days
$62.41
258305-004 Printronix MEDIA 105, 4.0" x 1.0
Ships Free in 3-5 Days
$76.61
258305-002 Printronix MEDIA 105, 3.0" x 2.0
Ships Free in 3-5 Days
$80.33
222113-COMPATIBLE AirTrack Ribbons, 4.33" x 1181|1182' Black Wax Ribbon, Compatible with Industrial printers and Paper Labels, Rolls per Case: 1, Core Size: 1", Priced per roll. Available as a case(222113-COMPATIBLE) Ships Today $12.60

The Printronix TT4M2-0101-00 is also known as PTX-TT4M2-0101-00 or TT4M2010100 .
