Zebra 110Xi4 Printer

"Zebra 110Xi4 series of built to last printers are legendary for their rugged durability, consistently outstanding print quality, fast print speed, long life, and unparalleled reliability in demanding applications. Print methods: Thermal transfer or direct thermal 32 bit 133 MHz RISC processor 8 MB Flash memory""""including 2.0 MB user-available non-volatile memory storage for downloadable objects Print speeds up to 14""/356 mm per second for increased batch and print/apply productivity LCD content and navigation customizable to user needs Large, easy-to-use LCD screen simplifies setup Flexible connectivity including simultaneous parallel/Ethernet Advanced ribbon- and media-low LCD/e-mail alerts On-board diagnostic tools and adjustments to ensure optimum print quality Internal real-time clock Auto calibration -printer calibrates when printer is turned on or when printhead is closed using approximately two labels Clear media side door - easy monitoring of supplies usage without opening the printer systems Thin film printhead with Element Energy Equalizer for superior print quality Serial RS-232 and bi-directional parallel ports""""with auto detect Internal ZebraNet 10/100 Print Server (Ethernet) Dual media sensors - transmissive and reflective, selectable through software or front panel"
Questions?
1-888-875-7170
We respond to every email

Earn up to $500 back on a new Zebra printer when you trade in any other printer.
Offer valid through December 31, 2016. Check eligibility and claim your rebate ›

Printer Type ?

Print Speed ?

  • 14 (16)

Interface Options

Maximum Print Width ?

Print Method ?

Print Resolution ?

Labels Per Day ?

Included Features

110Xi4 Options
Part # DescriptionAvailabilityPriceOrder
112-801-00200-REFURB 110Xi4, REFURBISHED/USED/REBUILT - Direct Thermal/Thermal Transfer printing, RFID ready, 203 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces, Rewinder, Peeler. Includes US power cord. Interface cables sold separately. Includes 90 day warranty.
Ships Free in 7+ Days
$1,406.25
112-801-00100-REFURB 110Xi4, REFURBISHED/USED/REBUILT - Direct Thermal/Thermal Transfer printing, RFID ready, 203 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces, Cutter, Catch Tray. Includes US power cord. Interface cables sold separately. Includes 90 day warranty.
Ships Free in 7+ Days
$1,562.50
112-801-00000-REFURB 110Xi4, REFURBISHED/USED/REBUILT - Direct Thermal/Thermal Transfer printing, RFID Ready, 203 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces. Includes US power cord. Interface cables sold separately. Includes 90 day warranty.
Ships Free in 7+ Days
$1,748.75
112-801-00000 110Xi4, Direct Thermal/Thermal Transfer printing, RFID Ready, 203 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces. Includes US power cord. Interface cables sold separately. Ships Free Today $2,435.25
Retail $2865
Save 15%
112-801-00100 110Xi4, Thermal transfer printing, RFID ready, 203 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces, Cutter, Catch Tray. Includes US power cord. Interface cables sold separately. Ships Free Today $3,001.35
Retail $3531
Save 15%
112-801-00200 110Xi4, Thermal transfer printing, RFID ready, 203 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces, Rewinder, Peeler. Includes US power cord. Interface cables sold separately. Ships Free Today $2,676.65
Retail $3149
Save 14%
113-801-00000 110Xi4, Thermal transfer printing, RFID ready, 305 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces. Includes US power cord. Interface cables sold separately. Ships Free Today $2,601.00
Retail $3060
Save 15%
113-801-00200 110Xi4, Thermal transfer printing, RFID ready, 305 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces, Rewinder, Peeler. Includes US power cord. Interface cables sold separately. Ships Free Today $2,839.00
Retail $3340
Save 15%
116-801-00001 110Xi4, Direct Thermal/Thermal Transfer printing, RFID ready, 609 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces. Includes US power cord. Interface cables sold separately. Ships Free Today $4,063.00
Retail $4780
Save 15%
116-801-00201 110Xi4, Thermal transfer printing, RFID ready, 609 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces, Rewinder, Peeler. Includes US power cord. Interface cables sold separately. Ships Free Today $4,303.55
Retail $5063
Save 14%
113-801-00100 110Xi4, Thermal transfer printing, RFID ready, 305 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces, Cutter, Catch Tray. Includes US power cord. Interface cables sold separately. Ships Free Today $3,164.55
Retail $3723
Save 14%
113-801-00203 110Xi4, Thermal transfer printing, RFID ready, 305 dpi, 4" print width, Ethernet/USB/RS-232/Parallel interfaces, Rewinder, Peeler, Clear Bi-Fold Media Side Door and Hanger. Includes US power supply. Interface cables sold separately.
Ships Free in 3-5 Days
$2,936.75
Retail $3455
Save 15%
116-801-00101 110Xi4, Thermal transfer Industrial Printer (600 dpi, Ethernet, USB, Serial (RS-232), and Parallel interfaces, 4" max print width, 16MB SDRAM, Cutter, Clear Media Side Door & 3" Media Spindle). Includes power supply. Cables sold separately. See accessories. Ships Free Today $4,628.25
Retail $5445
Save 15%
116-801-00204 110Xi4, Thermal transfer Industrial Printer (600 dpi, Ethernet, USB, Serial (RS-232), and Parallel interfaces, 4" max print width, 16MB SDRAM, Rewinder and Peeler, Clear Bi-fold Media Side Door & 3" Media Spindle). Includes power supply. Cables sold separately. See accessories.
Ships Free in 3-5 Days
$4,400.45
Retail $5177
Save 15%
112-801-00003 110Xi4, Thermal transfer Industrial Printer (203 dpi, Ethernet, USB, Serial (RS-232), and Parallel interfaces, 4" max print width, 16MB SDRAM, Clear Bi-fold Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories.
Ships Free in 3-5 Days
$2,533.85
Retail $2981
Save 15%
113-801-00070 110Xi4, Thermal transfer Industrial Printer (300 dpi, Ethernet, USB, Serial (RS-232), and Parallel interfaces, 4" max print width, 16MB SDRAM, Printhead element Out Detection, Clear Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories.
Ships Free in 3-5 Days
$2,676.65
Retail $3149
Save 14%
112-801-00000-GA 110Xi4, Thermal transfer Industrial Printer (203 dpi, Ethernet, USB, Serial (RS-232), and Parallel interfaces, 4" max print width, 16MB SDRAM, Clear Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories. This is the TAA compliant version of this product for government purchasers. Please Call for more information.
Ships Free in 3-5 Days
$2,545.75
113-801-00000-GA 110Xi4, Thermal transfer Industrial Printer (300 dpi, Ethernet, USB, Serial (RS-232), and Parallel interfaces, 4" max print width, 16MB SDRAM, Clear Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories. This is the TAA compliant version of this product for government purchasers. Please Call for more information.
Ships Free in 3-5 Days
$2,396.25
Retail $3195
Save 25%
112-8K1-00000 Thermal transfer printing, 4.09" print width, RS- 232 serial, USB 2.0, 802.11 b/g, Centronics parallel, 203 dpi, tear bar, North America power cord, media supply hanger. Ships Free Today $2,842.40
Retail $3344
Save 14%
112-8K1-00200 110Xi4,203 dpi, 10/100, REW/PEEL ZPL & XML CARD INCLUDED Ships Free Today $3,082.10
Retail $3626
Save 15%
113-8K1-00100 110Xi4, Thermal transfer Industrial Printer (300 dpi, Wi-Fi (card included), Ethernet, USB, Serial (RS-232), and Parallel interfaces, 4" max print width, 16MB SDRAM, Cutter, Clear Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories. Ships Free Today $3,570.00
Retail $4200
Save 15%
113-8K1-00000 110Xi4, 300 DPI, Wireless+, 10/100, ZebraNet B/G
Ships Free in 3-5 Days
$3,004.75
Retail $3535
Save 15%
112-8K1-00100 110Xi4, 203 dpi, with WIRELESS+, 10/100 RFID READY, CUTTER/TRAY Ships Free Today $3,407.65
Retail $4009
Save 14%
116-8K1-00201 110Xi4, 600 0/g US R 16 CDS
Ships Free in 3-5 Days
$4,709.00
Retail $5540
Save 15%
112-801-00203 110Xi4, 203 dpi, US, Serial/P/USB 10/100 REWIND/PEEL BIFOLD MED
Ships Free in 3-5 Days
$2,773.55
Retail $3263
Save 14%
113-8K1-00200 110Xi4, 300 DPI, WIRELESS+, 10/100, REWIND with PEEL Ships Free Today $3,244.45
Retail $3817
Save 15%
116-8K1-00001 110XI4, 600 Serial/Parallel/USB 10/100 B/G PRINT Serial 3-MEDIA SPNDL Ships Free Today $4,469.30
Retail $5258
Save 14%
112-8K1-00270 110Xi4, 203 dpi RFID Ready RS-232 Serial Parallel USB ZN RWD w peel 16MB
Ships Free in 3-5 Days
$3,159.45
Retail $3717
Save 15%
112-801-00070 110Xi4, RFID READY, 4" Thermal transfer TABLETOP, 203 dpi RFID READY, RS-232 SERIAL, PARALLEL, USB 2.0, INTERNAL ZebraNet 10/100, 16 SDRAM (PRINTHEAD ELEMENT OUT DETECTION) with ZPL II & XML
Ships Free in 3-5 Days
$2,513.45
Retail $2957
Save 15%
113-805-00200 110Xi4, TT PRINTER, 300 DPI, ARGENTINA CORD, SERIAL, PARALLEL, USB, INT 10/100, REWIND WITH PEEL
Ships Free in 3-5 Days
$2,839.00
Retail $3340
Save 15%

Page: 1 2 »

Zebra 110Xi4 Details

Standard Features
  • Print methods: Thermal transfer or direct thermal
  • Construction: 12-gauge steel frame
  • Single 32 bit 133 Mhz RISC processor

More Standard Features
  • 16 MB SD RAM; 8 MB non-volatile Flash memory
  • Automatic media/ribbon sensing capability
  • Improved head test for element out
  • Auto calibration
  • Clear media side door for ease of supplies monitoring
  • 300 unique darkness settings
  • RS-232, Parallel ports
  • USB 2.0 port
  • Internal ZebraNet 10/100 PrintServer
  • ZPL or ZPL II Programming Language
  • XML enabled printing
  • Mirror feature allows user-defined printer configurations to be retrieved from the network
  • Create and design customizable printer LCD menus
  • Large (240W x 128H pixel), graphical, multilingual, backlit LCD display
  • Transmissive and reflective media sensors
  • Multi-level Element Energy Equalizer (E3) for superior print quality
  • Unicode - Compliant
  • Intelligent printhead

Printer Specifications
Resolution: 203 dpi (8 dots/mm)
300 dpi (12 dots/mm)
600 dpi (23.5 dots/mm)
Memory
  • 16 MB SDRAM
  • 8 MB Flash
Print width: 4.0" (102mm)
Print length: 150" (3810 mm) maximum with 110Xi4 203 dpi using continuous media
Print speed: Up to 14" per second
Media sensors: Reflective, Transmissive
Media Characteristics
Maximum label and liner width: 4.5" (114mm)
Minimum label and liner width: .79" (20mm)
Maximum label and liner length: 39" (991mm) non-continuous to 150"
(3810mm) continuous media
Maximum roll diameter: 8.0" (203mm)
Core diameter: 3" (76mm)
Media thickness: .003" (.076mm) to .012" (.305mm)
Media types: black mark, continuous, roll-fed, die-cut, fanfold
Ribbon Characteristics
Outside diameter: 3.2" (81.3mm)
Standard length: 1476' (450m) or 984' (300m)
Ratio: 2:1 or 3:1 media roll to ribbon ratios
Ribbon width: .79" (20mm) to 4.33" (110mm)
Ribbon setup: Ribbon wound ink side out
ID Core: 1.0" (25.4 mm)
Operating Characteristics
Operating temperature TT: Operating temperature: 40F (5C) to 105F (40C)
Thermal transfer DT: Operating temperature: 32F (0C) to 105F (40C)
Direct thermal Storage temperatures: -40F (-40C) to 140F (60C)
Operating humidity: 20% to 85% non-condensing relative humidity
Storage humidity: 5% to 85% non-condensing relative humidity
Electrical: Universal power supply with power factor connection 90-264 VAC; 48 - 62 Hz
Agency approvals
  • BSMI
  • cTUVus
  • CCC
  • CE
  • C-Tick
  • EN55022 Class B
  • EN55024
  • EN61000-3-2,3
  • FCC Class B
  • GOST-R
  • ICES-003 Class B
  • IEC 60950-1 / EN60950
  • KCC
  • NOM
  • S Mark
  • STB
  • UkrSEPRO
  • VCCI
  • ZIK

Physical Characteristics
Width: 10.31" (261.9mm)
Height: 15.5" (393.7 mm)
Depth: 20.38" (517.5 mm)
Weight: 50 lbs (22.7 kg)
Related Products
Options
  • ZebraNet Wireless Plus Print Server
  • ZebraNet Internal Wireless Plus (Discontinued)
  • Internal IPv6 Print Server
  • IBM Twinax interface
  • IBM Coax interface
  • Rewind with peel
  • Cutter
  • Bi-fold media door with clear panel
  • Media supply spindle for 40 mm cores
  • 64MB Flash Memory with ZPL II and XML (with element out detection)
  • 64MB Flash Memory with ZPL II and XML (without element out detection)
  • 16MB SDRAM (Printhead element out detection) with ZPL II and XML
  • Scalable and international fonts
  • Applicator interface
  • ZebraDesigner
  • ZebraDesigner Pro
  • ZebraDesigner for XML
  • ZebraNet Bridge
  • Enterprise Connector
  • ZebraNet b/g Print Server
Communication and Interface Capabilities
  • USB 2.0 port (12 Mbits per second)
  • RS-232C/422/485 multi-drop (optional adaptor)
  • High-speed, bi-directional, IEEE 1284 parallel interface
  • ZebraNet Wireless Plus Print Server
  • ZebraNet 10/100 Print Server
  • IBM Twinax interface
  • IBM Coax interface
  • Applicator interface
  • IPV6 Print Server
  • ZebraNet b/g Print Server

Programming Languages
Core programming languages: ZPL II, ZPL, XML
Bar Codes/Symbologies
Linear Code 11
Code 39
Code 93
Code 128 with subsets A/B/C and UCC case codes
UPC-A
UPC-E
EAN-8
EAN-13
UPC and EAN 2 or 5 digit extensions
Plessey
Postnet
Standard 2-of-5
Industrial 2-of-5
Interleaved 2-of-5
Logmars
MSI
Planet Code
Codabar
2-dimensional Codablock
PDF417
Code 49
Data Matrix
MaxiCode
QR Code
TLC 39
MicroPDF
Aztec
RSS / GS1 DataBar family (12 barcodes)
Fonts and Graphics
  • Bitmap fonts A through H and GS symbols are expandable up to 10 times, height and width independent
  • Smooth scalable font (CG Triumvirate Bold Condensed) is expandable dot-by-dot, height and width independent
  • IBMCode Page 850 International Characters
