Emissions and Susceptibility: (CE): ETSI 300 330-2, ETSI
EN301-489-3, EN55022 Class-B, EN61000-3-2, EN61000-3-3 and
EN55024
Safety: CB Scheme IEC 60950: 1991 +A1 +A2 +A3 +A4, UL 60950 and
C-UL
Physical Characteristics
Width
7.9" (201 mm)
Height
6.8" (172 mm)
Depth
9.75" (248 mm)
Weight
3.2 lbs (1.4 kg)
Related Products
Options
8 MB Flash Memory w/ Real Time clock for a total of 12 MB
(10.75 MB available to user) for applications
Dispenser - Label peel and present with label taken sensor
ZebraNet PrintServer II (internal and external)
BAR-ONE Label Design Software
Communication and Interface Capabilities
Centronics Parallel (36 Pin) connector ports
RS-232 Serial Interface
USB v 1.1
ZebraNet PrintServer II
Programming Languages
Core programming languages
ZPL, ZPL II, Zebra BASIC Interpreter
Bar Codes/Symbologies
Linear
Code 11
Code 39
Code 93
Code 128
Codabar
UPC-A
EAN-8
Plessey
Interleaved 2-of-5
Standard 2-of-5
UPC-E
EAN-13
Industrial 2-of-5
Logmars
Postnet
MSI
Planet Code
EAN-14
UPC-A and UPC-E with 2 or 5 digit extensions
2-dimensional
Codablock
MaxiCode
PDF417
Data Matrix
TLC 39
QR Code
RSS
Fonts and Graphics
Character Fonts: Standard bitmapped Zebra fonts: A, B, C, D, E
(OCR-B), F, G, H, (OCR-A), GS, P, Q , R, S, T, U, V & Smooth font
(CG Triumvirate Bold Condensed).
Character Sets: IBM Code Page 850 International characters &
graphic symbols
Supports user defined fonts and graphics - including custom
logos
Bitmap fonts are expandable up to 10 times, height and width
independent. Fonts E and H (OCR-B and OCR-A), however, are not
considered in spec when expanded.
Smooth scalable font (CG Triumvirate Bold Condensed) is
expandable dot-by-dot, height and width independent, while
maintaining edges to a max. 1500 x 1500 dots.
IBM Code Page 850 International Characters available in fonts
A, B, D, E, F, G through software control.
Direct thermal, 203 dpi, 4 ips, 4" print width, parallel, serial & USB interfaces, 512KB RAM, 1MB flash. Includes U.S. power supply. Order cables separately. See accessories.
Direct thermal, 203 dpi, 4 ips, 4" print width, Serial, Parallel and USB Interfaces, 256K SRAM, 512K Flash, ASCII EPL2 Programming Language, RTC & U.S. power supply. Order cables separately. See accessories.
Direct Thermal printing, 203 dpi, 4" max print width, Serial, Parallel and USB Interfaces, Dispenser, Expanded Memory, and US power cord. Cables sold separately.
Direct Thermal printing, 203 dpi, 4" max print width, Serial, Ethernet, and USB Interfaces, European and Japanese Font Set, and US power cord. Cables sold separately.
