QN3-AUGA0000-00 - Zebra QLn 320 Portable Bar code Printer

Boost productivity and print anywhere with drop-resistant mobile printers that offer high-quality printing, easy integration, proactive alerts and convenient charging. Trust these mobile printers to improve efficiencies throughout operations–in the warehouse, shipping and receiving and merchandising. Quickly and easily print barcode labels, receipts, tickets and more, on-site and on-demand.

Questions?
1-888-875-7170
We respond to every email
Part # Description Availability Price Order
QN3-AUGA0000-00 QLn320, Direct thermal Mobile Printer (802.11b/g)
Information:   |  Download Zebra QLn 320 driver  |  Specifications  |  Zebra's QLn 320 page  |
Accessories:   |  Accessories/Options  |  Zebra QLn 320 service contract  |

QN3-AUGA0000-00 Details

Technical Information

  • Maximum Mono Print Speed: 4 in/s
  • Peel Facility: Yes
  • Maximum Print Resolution: 203 dpi
  • Print Color: Monochrome
  • Maximum Print Width: 2.90"
  • Recommended Use: Label Print
  • Features:
    • Peel Facility
    • Tear Bar
    • Label Odometer
    • Real Time Clock
  • Barcode Symbology Supported:
    • Code 39
    • Code 93
    • UCC/EAN 128
    • Code 128
    • Codabar
    • Interleaved 2 of 5
    • UPC-A
    • UPC-E
    • EAN-8
    • EAN-13
    • PDF-417
    • Micro PDF-417
    • Maxi Code
    • QR Code
    • RSS
    • GS1 DataBar
    • Aztec Code
    • Data Matrix
    • TLC 39
    • MSI
    • Plessey
    • POSTNET
    • FIM

General Information

  • Product Type: Direct Thermal Printer
  • Product Series: QLn
  • Brand Name: Zebra
  • Manufacturer: Zebra Technologies Corporation
  • Product Model: QLn320
  • Product Name: QLn320 Label Printer

Physical Characteristics

  • Height: 3.3"
  • Width: 4.6"
  • Depth: 6.8"
  • Form Factor: Portable
  • Weight (Approximate): 1.60 lb

Interfaces/Ports

  • USB: Yes
  • Serial Port: Yes

Other

  • Platform Supported: PC
  • Package Contents:
    • QLn320 Label Printer
    • Battery
    • QLn320 Label Printer
    • Battery
  • Certifications & Standards:
    • FCC Part 15, Subpart B
    • EN55022 Class-B
    • EN60950
    • EN55024
    • VCCI class B
    • EN55024
    • EN61000-4-2
    • EN61000-4-3
    • EN61000-4-4
    • EN61000-4-5
    • CE
    • UL
    • TUV
    • CSA

Media Types & Handling

  • Maximum Label Width: 3.13"
  • Maximum Label Length: 32"
  • Media Type:
    • Direct Thermal Label
    • Linered Label
    • Black Mark
    • Gap
    • Roll Fed
    • Die-cut Label
    • Receipt
    • Black Bar
  • Media Thickness: 6.50 mil
  • Media Sensor:
    • Label Taken Sensor
    • Transmissive Media Sensor
  • Label Core Size: 0.75"
  • Maximum Roll Diameter: 2.60"

Battery Information

  • Battery Included: Yes
  • Battery Rechargeable: Yes
  • Battery Chemistry: Lithium Ion (Li-Ion)

Fonts & Emulation

  • Language Emulation:
    • CPCL
    • ZPL

Power Description

  • Input Voltage: 7.4 V DC
  • Power Source: Battery

Network & Communication

  • Wireless LAN: Yes
  • Wireless LAN Standard: IEEE 802.11g

Memory

  • Standard Memory: 128 MB
  • Flash Memory: 256 MB

Warranty

  • Limited Warranty: 1 Year

Display & Graphics

  • Display Screen Type: LCD
Part # Description Availability Price Order
Z1AE-QNX0-3C0 Zebra Service Contract - 3 year, Essential, Purchased within 30 days of Device, 3 Day TAT NA, MX, 5 DAY TAT ROW, QLn220, QLn320, QLn420, 3 Years, Comprehensive
Ships Free in 3-5 Days
$176.88
Retail $230
Save 23%
TSP-US-MP-3 BCI Service Contracts, True Support contract 3-year - Mobile Printers Includes Tier 1 and Tier 2 Technical Helpdesk Support 7:30am-cst-5:00pm-cst, RMA Triage, OEM Service Contract management, Pre/post repair inspection and image loading. $60 per year for 3 years, billed annually.
Ships Free in 3-5 Days
$60.00

The Zebra QN3-AUGA0000-00 is also known as ZEB-QN3-AUGA0000-00 or QN3AUGA000000 .
