3M Touch Systems M2256PW Touchscreen
Part #: 98-0003-3512-9 | SKU: 3M 187568

The 3M-MicroTouch Multi-touch Display M2256PW incorporates 3M-MicroTouch Projected Capacitive Technology and offers full multi-touch capabilities with less than 6 millisecond response time for 20 simultaneous touches. This means fast, accurate touch response over the entire touch surface.

3M Touch Systems M2256PW Touchscreen

Part Details: 3M MicroTouch M2256PW 22" LCD Touchscreen Monitor - 8 ms - 22" Class - 1680 x 1050 - WSXGA+ - 16.7 Million Colors - 1,000:1 - 260 Nit - Speakers - DVI - USB - VGA - Black - 1 Year

Need a different version of the 3M Touch Systems M2256PW Touchscreen? View all 1 configurations

Additional Information

Manufacturer	3M Touch Systems
Model Name	M2256PW

3M Touch Systems M2256PW Specs (pdf)

General Information

Product Type: LCD Touchscreen Monitor
Brand Name: 3M
Manufacturer: 3M
Product Model: M2256PW
Product Name: M2256PW Touchscreen LCD Monitor
Product Line: MicroTouch

Technical Information

HDCP Supported: Yes
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Screen Mode: WSXGA+
Screen Size: 22"
Response Time: 8 ms

Physical Characteristics

VESA Mount Compatible: Yes
VESA Mount Standard: 100 x 100
Color: Black

Interfaces/Ports

USB: Yes
DVI: Yes
VGA: Yes

Video

Brightness: 260 Nit
Color Supported: 16.7 Million Colors
Maximum Resolution: 1680 x 1050
Contrast Ratio: 1,000:1

Other

Green Compliant: Yes
Green Compliance Certificate/Authority: RoHS

Warranty

Limited Warranty: 1 Year

Power Description

Operating Power Consumption: 70 W

Built-in Devices

Built-in Devices: Speaker

Extended Details

3M Touch Systems M2256PW Touchscreen Part #: 98-0003-3512-9 | SKU: 3M 187568
