| Manufacturer | APC |
|---|---|
| Model Name | Rack PDU |
General Information
- Product Type: Automatic Transfer Switch
- Brand Name: APC
- Manufacturer: American Power Conversion Corp
- Product Name: Automatic Transfer Switch (AP7750A)
Technical Information
- Receptacles: 10 x NEMA 5-15R
- Switching Time: 16 ms
- Plug/Connector Type: NEMA 5-15P
- Protection Type: Overload
Physical Characteristics
- Height: 1.7"
- Width: 17"
- Depth: 9.3"
- Form Factor: Rack-mountable
- Weight (Approximate): 10.36 lb
- Color: Black
Other
- Package Contents:
- Automatic Transfer Switch (AP7750A)
- Rack Mounting Brackets
- User Manual
- Automatic Transfer Switch (AP7750A)
- Rack Mounting Brackets
- User Manual
- Green Compliant: Yes
- Green Compliance Certificate/Authority:
- RoHS
- REACH
- Certifications & Standards:
- FCC Part 15 Class A
- ICES-003
- TUV-C
- TUV-NURTL
- VCCI Class A
Power Description
- Current:
- 15 A Total Current Draw Per Phase
- 12 A Derated Input Current
- Load Capacity: 1.44 kVA
- Input Voltage:
- 100 V AC
- 120 V AC
- Frequency: 60 Hz
Warranty
- Limited Warranty: 2 Year Limited
