| Manufacturer AIDC | APC |
|---|---|
| Model Name | Smart-UPS Series |
Technical Information
- Receptacles:
- 6 x NEMA 5-15R
- 2 x NEMA 5-20R
- Plug/Connector Type: NEMA L5-30P
- Cord Length: 8 ft
- Emergency Power OFF: Yes
General Information
- Product Type: Line-interactive UPS
- Brand Name: APC
- Manufacturer: American Power Conversion Corp
- Product Name: Smart-UPS 3000VA
- Product Line: Smart-UPS
Physical Characteristics
- Height: 3.5"
- Width: 19"
- Depth: 26"
- Rack Height: 2U
- Weight (Approximate): 96 lb
- Color: Black
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
- Total Number of Expansion Slots: 1
Other
- Package Contents:
- Smart UPS
- Software CD
- Rack Mounting Brackets
- Signalling RS-232 cable
- USB cable
- User Manual
- Smart UPS
- Software CD
- Rack Mounting Brackets
- Signalling RS-232 cable
- USB cable
- User Manual
- Certifications & Standards:
- BSMI
- CSA
- UL 1449
- UL 1778
- FCC Part 15 Class A
- Additional Information:
- Automatic Self Test
- Automatic Voltage Regulation (AVR)
- Lightning and Surge Protection
- Load Meter
- Network-grade line conditioning
- Wide input voltage range
Controls/Indicators
- Status Indicators:
- On Line
- On Battery
- Replace Battery
- Overload
- Wiring Fault
- Status
Power Description
- Load Capacity (VA): 3000 VA
- Load Capacity (Watt): 2700 W
- Input Voltage: 110 V AC
- Output Voltage: 120 V AC
- Surge Energy Rating: 480 J
- Waveform Type: Sine Wave
Battery Information
- Backup/Run Time (Half Load): 11.30 Minute
- Backup/Run Time (Full Load): 3 Minute
- Battery Characteristics: Spill-proof, Maintenance-free
- Battery Chemistry: Sealed Lead Acid
- Hot Swappable: Yes
Management
- Network Management: SNMP Manageable
- Battery Management: Intelligent Battery Management
- Alarm:
- On Battery
- Low Battery
Environmental Conditions
- Temperature: 113°F (45°C)
- Thermal Dissipation: 400 BTU/h
Warranty
- Limited Warranty: 2 Year
