Additional Information
| Manufacturer AIDC | HPE Aruba |
|---|---|
| Model Name | Parts |
| Wireless Type | Wi-Fi, Wi-Fi 4: 802.11n |
Technical Information
- Wireless LAN Standard: IEEE 802.11n
- ISM Band: Yes
- UNII Band: Yes
- ISM Minimum Frequency: 2.40 GHz
- UNII Minimum Frequency: 5.15 GHz
- Antenna Gain:
- 4.5 dBi
- 5.5 dBi
- Antenna Type: Omnidirectional Antenna
- Total Number of Antennas: 6
- Wireless Transmission Speed: 450 Mbps
- ISM Maximum Frequency: 2.48 GHz
- UNII Maximum Frequency: 5.85 GHz
- Features:
- Cable Lock Slot
- MIMO Technology
General Information
- Product Type: Wireless Access Point
- Product Series: 110
- Brand Name: Aruba Networks
- Manufacturer: Aruba Networks, Inc
- Product Model: AP-115
- Product Name: AP-115 Wireless Access Point
Physical Characteristics
- Height: 1.8"
- Width: 7.1"
- Depth: 7.1"
- Form Factor:
- Ceiling Mountable
- Wall Mountable
- Weight (Approximate): 1.43 lb
Interfaces/Ports
- Ethernet Port: Yes
- Fast Ethernet Port: Yes
- Gigabit Ethernet Port: Yes
- 10Gigabit Ethernet Port: No
- Number of Network (RJ-45) Ports: 1
- PoE (RJ-45) Port: No
- USB: Yes
- HDMI: No
- VGA: No
- Audio Line Out: No
- Serial Port: No
- Network (RJ-11): No
- Powerline: No
- Management Port: Yes
Other
- Package Contents:
- AP-115 Wireless Access Point
- Mounting Brackets
- AP-115 Wireless Access Point
- Mounting Brackets
- Certifications & Standards:
- FCC/Industry of Canada
- CE Marked
- R&TTE Directive 1995/5/EC
- Low Voltage Directive 72/23/EEC
- EN 300 328
- EN 301 489
- EN 301 893
- UL/IEC/EN 60950
- EN 60601-1-1
- EN60601-1-2
- CB Scheme Safety
- cTUVus
- IEEE Standards:
- 802.11a/b/g/n
- 802.3af/at/az
Power Description
- Input Voltage: 12 V DC
- Power Source:
- AC Adapter
- PoE
Management & Protocols
- Management: Adaptive Radio Management
Warranty
- Limited Warranty: Lifetime
