HPE Aruba 530 Series Wireless Access Points HPE Aruba 530 Series Wireless Access Points
new

HPE Aruba 530 Series Wireless Access Points
Part #: JZ332A | SKU: HPE766914

This hospitality-grade Wi-Fi 6E access point combines high performance and flexibility in a compact, wall-mount design. Dual 2×2:2 radios can operate on any two bands—2.4 GHz, 5 GHz or 6 GHz—to balance coverage and capacity based on deployment needs, delivering up to 3.6 Gbps peak aggregate throughput. Ideal for hotels, guesthouses and student residences, it handles simultaneous HD video streaming, VoIP calls and IoT devices with ease. A 2.5 GbE uplink plus four 1 GbE PoE-PSE downlinks and a USB-A port support network, power and edge computing services. Built-in multi-GNSS positioning, TPM 2.0 security and thermal shutdown protect both connectivity and hardware under heavy use.

Key Features

  • Dual-radio tri-band 802.11ax (Wi-Fi 6E) 2×2:2 MIMO
  • 3.6 Gbps peak throughput (6 GHz 2.4 Gbps + 5 GHz 1.2 Gbps)
  • 1×2.5 GbE uplink; 4×1 GbE PoE-PSE downlinks; USB 2.0 host port
  • Multi-GNSS L1 receiver for GPS/Galileo/GLONASS/BeiDou positioning
  • TPM 2.0 secure boot and credential storage
  • Automatic thermal shutdown for hardware protection

Specifications

  • Power: PoE (802.3at/802.3bt) or 12 V DC
  • Max Power: 14.9 W (DC) / 27.5 W (PoE-PSE)
  • Operating Temp: 0 °C–50 °C; Humidity: 5 %–95 % non-condensing
  • Dimensions: 105 × 40 × 153 mm; Weight: 500 g

HPE Aruba 530 Series Wireless Access Points

Part Details: Wireless Access Points - HPE Aruba 530 Series - AP-534 (US) Dual Radio 4x4:4 802.11ax External Antennas Unified Campus AP
Need a different version of the HPE Aruba 530 Series Wireless Access Points? View all 20 configurations
MSRP: $2,028.00 Price: $1,829.78
In Stock

Additional Information

Manufacturer HPE Aruba
Model Name 530 Series

Recommended Accessories for Model: HPE Aruba 530 Series Wireless Access Points

  • HPE Aruba S1F80A Antenna
    Part #: S1F80A | SKU: HPE766854

    Antennas - HPE Aruba - AP-ANT-312 Direct-Mount RP-SMA Tri-band 1x1 Low-Profile Omni Dipole Antenna
    MSRP: $33.00 Price: $32.93
    In Stock

  • HPE Aruba JW124A Cables, Connectors, and Adapters
    Part #: JW124A | SKU: HPE766862

    Cables - Connectors - and Adapters - HPE Aruba - PC-AC-NA AC Power Cord (North America) 125V/10A 1.8 m C13 to NEMA 5-15P
    Price: $9.59
    In Stock

  • HPE Aruba R3K01A Network Management Devices
    Part #: R3K01A | SKU: HPE764910

    Network Management Devices - Aruba - 48V/50W AC/DC Power Adapter - Type C
    MSRP: $89.00 Price: $63.74
    In Stock

  • HPE Aruba 750 Series Mounting Hardware and Stands
    Part #: S4K79A | SKU: HPE766840

    Mounting Hardware and Stands - HPE Aruba 750 Series - AP-MNT-U Campus Access Point Type U Universal Mount Bracket Kit
    MSRP: $65.00 Price: $58.65
    In Stock

  • HPE Aruba 750 Series Mounting Hardware and Stands
    Part #: S0J40A | SKU: HPE766841

    Mounting Hardware and Stands - HPE Aruba 750 Series - AP-MNT-MP10-U Campus AP 10-Pack Universal Mount Bracket Kit
    MSRP: $545.00 Price: $491.73
    In Stock
