HPE Aruba 503 Series Wireless Access Points HPE Aruba 503 Series Wireless Access Points
new

HPE Aruba 503 Series Wireless Access Points
Part #: R8M99A | SKU: HPE766935

This compact desktop Wi-Fi 6 remote access point brings enterprise-class wireless to home offices and small branches without on-site expertise. Dual 2×2:2 radios deliver up to 1.49 Gbps combined throughput, leveraging OFDMA and MU-MIMO for streaming, conferencing and cloud apps. Three 1 GbE ports (one uplink, two PoE-PSE downlinks) plus an optional USB LTE Cat 12 modem ensure uninterrupted connectivity over Ethernet, PoE or cellular backhaul. Zero Touch Provisioning, WPA3/Enhanced Open security and Dynamic Segmentation simplify setup and protect traffic. A USB 2.0 host port lets you attach IoT or security appliances right at the AP.

Key Features

  • Dual-radio 2×2:2 MIMO on 2.4 GHz & 5 GHz, up to 1.49 Gbps combined
  • OFDMA, MU-MIMO and Target Wake Time (TWT) for multi-user efficiency
  • WPA3, Enhanced Open and Dynamic Segmentation security
  • Three 1 GbE ports: 1×uplink + 2×PoE-PSE downlinks
  • Optional USB LTE Cat 12 modem for cellular backhaul
  • Zero Touch Provisioning via Aruba Central cloud
  • USB 2.0 host port for local edge services

Specifications

  • Radio Rates: 2.4 GHz HE40 up to 574 Mbps; 5 GHz HE80 up to 1.2 Gbps
  • Ports: 3×1 GbE (RJ-45), USB-A host, USB-C power input, serial console
  • Power: 12 V DC (18 W adapter) or PoE-PSE downlink support
  • Max Power Draw: 15.4 W (worst-case), idle 4.0 W
  • Operating: 0 °C–50 °C; 5 %–93 % RH non-condensing
  • Antenna: integrated omni-directional, 3.9 dBi @2.4 GHz, 5.1 dBi @5 GHz
  • Security slot: Kensington lock
  • Form factor: desktop; mount kits available separately

HPE Aruba 503 Series Wireless Access Points

Part Details: Wireless Access Points - HPE Aruba 503 Series - Access Point-503 (US) Dual Radio 2x2:2 802.11ax Wi-Fi 6 Campus Access Point
Need a different version of the HPE Aruba 503 Series Wireless Access Points? View all 7 configurations
MSRP: $595.00 Price: $536.84
In Stock

Additional Information

Antenna Internal
Environment Indoor
MIMO 2x2:2
Manufacturer HPE Aruba
Mesh Yes
Model Name 503 Series

Recommended Accessories for Model: HPE Aruba 503 Series Wireless Access Points

  • HPE Aruba JW124A Cables, Connectors, and Adapters
    Part #: JW124A | SKU: HPE766862

    Cables - Connectors - and Adapters - HPE Aruba - PC-AC-NA AC Power Cord (North America) 125V/10A 1.8 m C13 to NEMA 5-15P
    Price: $9.59
    In Stock

  • HPE Aruba 503 Series Mounting Hardware and Stands
    Part #: JW044A | SKU: HPE767037

    Mounting Hardware and Stands - HPE Aruba 503 Series - AP-220-MNT-C1 2x Ceiling Grid Rail Adapter for Basic Flat Rails Mount Kit
    Price: $31.69
    In Stock

  • HPE Aruba 503 Series Mounting Hardware and Stands
    Part #: JW045A | SKU: HPE767038

    Mounting Hardware and Stands - HPE Aruba 503 Series - AP-220-MNT-C2 2x Ceiling Grid Rail Adapter for Interlude and Silhouette Mount Kit
    Price: $31.69
    In Stock

  • HPE Aruba 503 Series Mounting Hardware and Stands
    Part #: JW046A | SKU: HPE767040

    Mounting Hardware and Stands - HPE Aruba 503 Series - HPE AP-220-MNT-W1 Flat Surface Wall/Ceiling Black AP Basic Flat Surface Mount Kit
    Price: $31.54
    In Stock

  • HPE Aruba JY728A Cables, Connectors, and Adapters
    Part #: JY728A | SKU: HPE766866

    Cables - Connectors - and Adapters - HPE Aruba - AP-CBL-SERU Micro-USB TTL3.3V to USB2.0 AP Console Adapter Cable
    MSRP: $35.00 Price: $25.07
    In Stock
