AD Accessory M730
Overview
The AD Accessory M730 is engineered for outstanding performance in tagging small items, especially suited for accessories and cosmetic products. It operates within the UHF frequency range of 860 - 960 MHz and incorporates the Impinj M730 chip for enhanced functionality.
Specifications
- Frequency Range: UHF 860 - 960 MHz
- Integrated Chip: Impinj M730
- Antenna Size: 30 x 15 mm / 1.20 x 0.60 in
- Global Standard: ISO 18000-63, EPC Class 1 Gen 2
- Target Industries: Apparel, Healthcare
- Intended Uses: Children's Accessories, Fashion Jewelry and Sunglasses, Pharmaceuticals and Healthcare
Compliance
- RoHS: Meets EU Directive 2011/65/EC and Directive (EU) 2015/863
- REACH: Adheres to Regulation (EC) No. 1907/2006
Features and Benefits
The AD Accessory M730 delivers top-tier performance with superior close-coupling capabilities, making it perfect for tagging small-sized items. The 30 x 15 mm antenna design facilitates excellent bulk reading when applied to compact products. It boasts a 128-bit EPC memory and a 96-bit Tag Identifier (TID) featuring a 48-bit unique serial number pre-encoded into the TID.
Form Factor and Delivery Options
With a streamlined 33 mm (1.3 inch) form factor, the AD Accessory M730 is easily adaptable to end-use applications. It is offered in dry, wet, and paper tag formats for versatile application.
Quality and Environmental Assurance
The AD Accessory M730 inlays and tags comply with ISO 9001:2015 for Quality Management and ISO 14001:2015 for Environmental Management, ensuring a dependable and cutting-edge product fit for diverse application needs, particularly in retail settings.
Technical Attributes
Orientation Sensitivity and Range: Engineered for optimal efficiency
EPC and User Memory: 128-bit / 0-bit
TID Memory: 96-bit / 48-bit unique serial number
Product Identifiers: 3008300 / IL-604218, 3008304 / IL-600040, 3008305 / IL-604223
Delivery Options: Dry inlay, Wet inlay, Label
Die-Cut Measurements: 33 x 18 mm / 1.30 x 0.70 in
Antenna Material: AL, 1.0 mil / 25 µm
Inlay Material: PET
Face Sheet Choices: No face, Clear PET, Mid-gloss paper
Standard Pitch: 20 mm / 0.787 in
Web Width: 36 mm / 1.4 in
Core Dimension: 76 mm / 3 in
Reel Quantity: 10,000 pcs/reel, 20,000 pcs/box; 5,000 pcs/reel, 15,000 pcs/box
Temperature Range: -40 °C to 85 °C / -40 °F to 185 °F
Certification: ARC spec Q
Handling and Use
Users should conduct thorough testing of the AD Accessory M730 under actual usage conditions to confirm it meets their specific needs. It is sensitive to electrostatic discharge, and standard industry practices for electronics/RFID should be followed to reduce environmental impact and static charge.
Avery-Dennison AD Accessory M730 Specs
Refine Your Options
-
Avery-Dennison AD Accessory M730 RFID Tag
Part #: 3008305 | SKU: AVE759160RFID Tag - Avery-Dennison AD Accessory M730 - RFID Paper Label - 1.3 x 0.7 - Impinj Monza M730 Chip - AD Accessory M730 inlay - UHF Frequency - Ideal for Children Accessories - Fashion Jewelry and Sunglasses - Pharmaceutical and Healthcare.
