Avery-Dennison AD Force M775 RFID Tag

Introducing the AD Force M775, an innovative RFID tag tailored for the apparel sector, delivering outstanding features for brand security and supply chain optimization. Functioning within the UHF frequency range of 860 - 960 MHz, the AD Force M775 is integrated with the Impinj M775 chip, celebrated for its superior reading sensitivity and cryptographic prowess. This state-of-the-art chip includes a cryptographic engine based on ISO/IEC 29167-11 and a unique cryptographic key programmed by Impinj, facilitating real-time item authentication via the Impinj Authentication Service. This capability dramatically mitigates the risk of counterfeiting by validating each product throughout the supply chain.The AD Force M775 features a memory setup of 128 bits of EPC memory and 32 bits of user memory, complemented by a 96-bit TID with a 48-bit serial number. This setup boosts its sensitivity and readability over earlier Impinj IC versions. The tag comes in both dry and wet formats, featuring a 40# paper antenna carrier and a label that is printable via thermal transfer.Adhering to ISO 18000-63 TYPE C, the AD Force M775 aligns with rigorous global standards, ensuring dependability and excellence. It complies with RoHS and REACH, following EU Directive 2011/65/EU and Directive (EU) 2015/863, along with Regulation (EC) No. 1907/2006. Its quality is further assured by ISO 9001:2015 and ISO 14001:2015 certifications, as well as ARC accreditation from Auburn Universitys RFID Lab, confirming its superior quality.The AD Force M775 is crafted to perform optimally within temperatures ranging from -40 °C to 85 °C (-40 °F to 185 °F), making it adaptable to diverse environmental conditions. Its size measures 50 x 30 mm (1.969 x 1.181 in), and it is offered in various formats, such as dry inlay, wet inlay, and label.For more details or to make inquiries, please reach out to Avery Dennison at rfid.averydennison.com/contact or dial +1-678-617-2359.

Details

• chip: Impinj M775 / Impinj M750
• Frequency: UHF 814, 860-865 (Europe) / 902-928 MHz (North America)
• Approvals: ISO18000-63 Type C>
