Avery-Dennison AD Midas Flagtag M750 RFID Tag

The AD Midas Flagtag® M750 is an adaptable RFID tag crafted for precise item-level tagging, excelling on metallic surfaces. Functioning within the UHF frequency spectrum of 860 - 960 MHz, this tag incorporates the Impinj M750 chip, offering a 96-bit Electronic Product Code (EPC), 32-bit user memory, and a 96-bit unique TID with a distinct 48-bit serial number. It adheres to global standards ISO 18000-6C and EPC Class 1 Gen 2, making it ideal for use in sectors such as automotive, logistics, industrial, and aviation.The AD Midas Flagtag® M750 boasts a compact design, with antenna dimensions of 34.4 x 18 mm (1.36 x 0.71 in), and measures 43 x 21 mm (1.7 x 0.83 in) as a standard flat paper tag. Its innovative design includes a flag section that must extend beyond metal surfaces, leveraging the metal as an antenna component to boost performance. This tag is exceptionally effective for tracking assets on metal and managing supply chains, even in environments with metal and liquid presence.Built with a PET inlay substrate and a white PET face sheet, the AD Midas Flagtag® M750 is available in wet delivery formats, ensuring robust performance and longevity. It complies with RoHS EU Directive 2011/65/EU, Directive (EU) 2015/863, and REACH Regulation (EC) No. 1907/2006, and is produced under ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management standards.Adhesive choices for the tag include RA25 and RA2, with standard pitch options of 24 mm (0.945 in) and 27 mm (1.063 in), and a web width of 46 mm (1.811 in). It is offered in reels of 5000 units or boxes of 10000 units, with a core size of 76 mm (3 in). The AD Midas Flagtag® M750 is operational within a temperature range of -40 °C to 85 °C (-40 °F to 185 °F).For best results, users should adhere to specific folding guidelines: remove the tag from the substrate material, fold the white rectangular part along the perforation line to envelop the transponder, and apply the tag to the metallic surface with the transponder area exposed, allowing the folded flag to protrude.The AD Midas Flagtag® M750 provides a cutting-edge solution for effective and dependable item-level tagging in diverse industries, ensuring superior performance and adherence to rigorous standards.

Technical Summary

• Size: 43 x 21 mm (1.7 x 0.83 in) flat with flag, 34.4 x 18 mm (1.36 x 0.71 in) antenna
• Frequency: 860 - 960 Mhz
• Chip: Impinj M750
• Standards: ISO 18000-63 / EPC C1G2
• Material: PET
• Delivery format: wet
• RoHS: yes
• Core: 3inch
• Temperature range: -40°C to +85°C / -40°F to +185°F
