Avery-Dennison AD Miniweb M830 RFID Tag

The AD Miniweb M830 inlays from Avery Dennison Smartrac are meticulously designed for versatile use in retail, fashion, and industrial settings. These compact inlays ensure high performance, making them perfect for tagging a wide array of items. Equipped with the Impinj M830 IC, the AD Miniweb M830 offers 128-bit EPC memory, a 96-bit unique factory-locked TID, and a 48-bit unique serial number embedded into the TID. This sophisticated IC boosts readability, ensuring dependable scanning of small tags at high volumes and speeds, crucial for international IoT applications.The AD Miniweb M830 inlay features a 42 x 16 mm (1.654 x 0.630 in) antenna footprint and is available in dry inlay, wet inlay, and pressure-sensitive label formats. Adhering to ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management standards, each AD Miniweb M830 inlay is a dependable and cutting-edge solution for various applications, especially in retail. Avery Dennison has received its first major ARC accreditation for quality from the RFID Lab at Auburn University.Key specifications for the AD Miniweb M830 include a UHF frequency range of 860 - 960 MHz, direct chip attach technology, and compatibility with the ISO/IEC 18000-63 Type C standard. These inlays are suitable for diverse sectors such as apparel, logistics, and healthcare, supporting uses like brand protection, supply chain efficiency, and home essentials. They are RoHS compliant with EU Directive 2011/65/EU and 2015/863.Available in dry inlay, wet inlay, and label formats, the AD Miniweb M830 has die-cut dimensions of 45 x 18 mm (1.772 x 0.709 in). The inlay substrate is PET, with a mid-gloss paper face sheet for the label format. They feature a standard pitch of 20 mm (0.787 in) and a web width of 48 mm (1.890 in), using a core size of 76 mm (3 in). Inlays are supplied in reels containing between 5,000 and 20,000 pieces, contingent on the format, and can function in temperatures from -40 °C to 85 °C (-40 °F to 185 °F). The AD Miniweb M830 is engineered for non-metal surfaces and complies with the ARC Specification Guide.For more details or questions, reach out to Avery Dennison Smartrac at rfid.averydennison.com/contact or phone +1-678-617-2359.

Features and Benefits

• Engineered for small items and high-speed applications
• Impinj M830 Tag Chip with exceptional performance in compact form
• Global UHF coverage
• Multiple inlay and label formats
• Inlays delivered on-demand with production facilities close to tagging operations
