| Manufacturer AIDC | Cisco |
|---|---|
| Model Name | Aironet 1400 Series Wireless Bridge |
Cisco Aironet 1400 Series Wireless Bridge Specs
Technical Information
- Wireless LAN Standard: IEEE 802.11a
- UNII Band: Yes
- Outdoor Antenna Range: 23 Mile
- UNII Minimum Frequency: 5.73 GHz
- Antenna Gain: 28 dBi
- Antenna Type: Dish Antenna
- Wireless Transmission Speed: 54 Mbps
- UNII Maximum Frequency: 5.80 GHz
- Antenna Connector: N-Type
- Wireless Security:
- Authentication:
- 802.1x support including LEAP to yield mutual authentication and dynamic per-user, per-session encryption keys
- Encryption:
- Support for static and dynamic IEEE 802.11 WEP keys of 40 bits and 128 bits
- Pre-standard TKIP WEP enhancements: key hashing (per packet keying) and Message Integrity Check (MIC)
General Information
- Product Type: Wireless Bridge
- Product Series: 1400
- Brand Name: Cisco
- Manufacturer: Cisco Systems, Inc
- Product Model: 1410
- Product Name: Aironet 1410 Wireless Bridge
- Product Line: Aironet
Physical Characteristics
- Height: 3.6"
- Depth: 11.6"
- Form Factor:
- Mast-mountable
- Wall Mountable
- Weight (Approximate): 10 lb
Interfaces/Ports
- Fast Ethernet Port: Yes
Other
- Package Contents:
- Bridge unit
- Power injector unit (with mounting screws and wall anchors)
- Power module and AC power cord (with mounting screws and wall anchors)
- Two dual-coax cables [20 ft (6.1 m) and 50 ft (15.2 m)]
- Mounting kit and hardware:
- Multi-function mount (consisting of two bridge brackets and one tower or mast bracket)
- Two tower clamps (U-bolts) with four nuts and washers
- Four bolts, lock washers, and washers for securing the bridge brackets to the tower or mast bracket
- Four bolts and lock washers for securing the bridge brackets to the bridge
- Grounding block and mounting screws
- Ground lug for the bridge with screws
- Weatherproofing kit (consisting of Coax Seal and electrical joint compound)
- Quick Start Guide: Cisco Aironet 1400 Series Wireless Bridge
- Cisco Aironet 1400 Series Wireless Bridge Mounting Instructions
- Cisco product registration and Cisco documentation feedback cards
- Bridge unit
- Power injector unit (with mounting screws and wall anchors)
- Power module and AC power cord (with mounting screws and wall anchors)
- Two dual-coax cables [20 ft (6.1 m) and 50 ft (15.2 m)]
- Mounting kit and hardware:
- Multi-function mount (consisting of two bridge brackets and one tower or mast bracket)
- Two tower clamps (U-bolts) with four nuts and washers
- Four bolts, lock washers, and washers for securing the bridge brackets to the tower or mast bracket
- Four bolts and lock washers for securing the bridge brackets to the bridge
- Grounding block and mounting screws
- Ground lug for the bridge with screws
- Weatherproofing kit (consisting of Coax Seal and electrical joint compound)
- Quick Start Guide: Cisco Aironet 1400 Series Wireless Bridge
- Cisco Aironet 1400 Series Wireless Bridge Mounting Instructions
- Cisco product registration and Cisco documentation feedback cards
- Certifications & Standards:
- SNMP compliance: v1 and v2
- IEEE:
- 802.1x
- 802.11
- 802.11i
- 802.11a
- 802.11b
- Safety:
- UL 60950
- CSA C22.2 No. 60950-00
- IEC 60950
- EN 60950
- Radio Approvals:
- FCC Part 15.207, 15.407 & 15.209 Class B
- ICES-003 Class B (Canada)
- Canada DGTP-010
- FCC Bulletin OET-65C
- Industry Canada RSS-102, RSP100, RSS 210 Issue 5
- EMI and Susceptibility (ClassB):
- FCC Part 15.107 & 15.109 Class B
- ICES-003 Class B (Canada)
- EN 55022 Class B
- EN 55024
- Additional Information:
- Antenna Range: Measured with Non-root 28 dBi dish antenna
- Antenna Connector: One N-Type connector for professional installations
- Enclosure: NEMA-4, aluminum
- Uplink: 100 Mbps over dual coaxial cables
- DC Power: 48 VDC +/-2V
- Status LED:
- Install
- Radio
- Status
- Ethernet
Management & Protocols
- Management:
- Configuration support:
- Telnet
- HTTP
- FTP
- TFTP
- SNMP
Power Description
- Input Voltage:
- 48 V DC
- 110 V AC
- Power Source: AC Adapter
Warranty
- Limited Warranty: 1 Year
