Cisco Aironet 1200 Series Wireless Access Points Cisco Aironet 1200 Series Wireless Access Points

Cisco Aironet 1200 Series Wireless Access Points
Part #: AIR-LAP1231G-A-K9 | SKU: CIS40443

The Cisco Aironet 1200 Series Access Point sets the enterprise standard for next-generation high performance secure manageable and reliable wireless local-area networks (WLANs) while also providing investment protection because of its upgrade capability and compatibility with current standards. The modular design of the Cisco Aironet 1200 supports Institute of Electrical and Electronic Engineers (IEEE) 802.11a and 802.11b technologies in both single- and dual-mode operation. You can configure the Cisco Aironet 1200 to meet customer-specific requirements at the time of purchase and then reconfigure and upgrade the product in the field as these requirements evolve. In addition the Cisco Aironet 1200 Series creates a wireless infrastructure that provides customers with maximum mobility and flexibility enabling constant connection to all network resources from virtually anywhere wireless access is deployed.

Cisco Aironet 1200 Series Wireless Access Points

Part Details: 1231 Access Point (802.11g LWAPP AP Dual RP-TNC:A CBUS Slot FCC Config)
Need a different version of the Cisco Aironet 1200 Series Wireless Access Points? View all 6 configurations

Additional Information

Manufacturer AIDC Cisco
Model Name Aironet 1200 Series
Cisco Aironet 1200 Series Specs Cisco Aironet 1200 Series Specs (pdf)

Technical Information

  • Wireless Technology: IEEE 802.11b/g
  • Frequency Band/Bandwidth: 2.4GHz FCC
  • Frequency Band/Bandwidth Details: 2.412 to 2.462GHz IEEE 802.11b/g FCC
  • Antenna: with RP-TNC
  • Antenna Range:
    • 490ft @ 11Mbps Outdoors IEEE 802.11b
    • 700ft @ 1 Mbps Outdoors IEEE 802.11b
    • 220ft @ 11Mbps Indoor IEEE 802.11b
    • 410ft @ 1 Mbps Indoor IEEE 802.11b
    • 110ft @ 54 Mbps Outdoors IEEE 802.11g
    • 650ft @ 6 Mbps Outdoors IEEE 802.11g
    • 90ft @ 54 Mbps Indoor IEEE 802.11g
    • 300ft @ 1 Mbps Indoor IEEE 802.11g
  • Transmission Speed:
    • 11Mbps Auto-fallback IEEE 802.11b
    • 1Mbps IEEE 802.11b
    • 54Mbps Auto-fallback IEEE 802.11g
    • 6Mbps IEEE 802.11g
  • Channels:
    • 11 Channel(s)Operating Americas
    • 3 Channel(s)Nonoverlapping IEEE 802.11b/g
  • Transmit Power:
    • -1dBm to 17dBm IEEE 802.11a
    • 0dBm to 17dBm IEEE 802.11b
  • Receiver Sensitivity:
    • -72 dBm Typical @ 54Mbps IEEE 802.11a
    • -87 dBm Typical @ 6Mbps IEEE 802.11a
    • -85 dBm Typical @ 11Mbps IEEE 802.11b
    • -94 dBm Typical @ 1Mbps IEEE 802.11b
  • Wireless Security: WPA WPA2 (802.11i) Cisco TKIP Cisco message integrity check (MIC) IEEE 802.11 WEP IEEE 802.1X EAP
  • Modulation: DSSS OFDM
  • Output Power: 13W

General Information

  • Manufacturer: Cisco Systems
  • Product Line: Aironet
  • Product Name: Aironet 1200 Series Access Point

Physical Characteristics

  • Dimensions: 1.6" (41mm) x 6.5" (165mm) x x 7.2" (183mm) - Add 0.517 in. (1.31 cm) height for mounting bracket
  • Weight: 1.72 lb (0.78 kg) - Add 0.4 lb (0.181 kg) for mounting bracket

Environmental Conditions

  • Temperature:
    • -40°C (-40°F) to 85°C (185°F) Non-operating
    • -20°C (-4°F) to 50°C (122°F) Operating
  • Humidity: 10 to 90% Non-condensing

Agency Approvals

  • Agency Approvals: Wi-Fi UL 60950 IEC 60950 UL 2043 FCC WPA2 WPA AES, TKIP RSS-102 IEEE 802.11i IEEE 802.1x IEEE 802.11b IEEE 802.11g

Warranty

  • Manufacturer Warranty: 1 Year(s)
Extended Details
