Cisco C819 Data Networking
Part #: C819HGW+7-A-A-K9 | SKU: CIS227715

The Cisco 819 ISRs provide Internet, VPN, data, and backup capability to corporate teleworkers and remote and small offices of fewer than 20 users. These routers are capable of bridging and multiprotocol routing between LAN and WAN ports and provide advanced features such as antivirus protection. The Cisco 819 ISRs are fixed-configuration data routers that provide four 10/100 Fast Ethernet (FE), 1 Gigabit Ethernet (GE), and WAN connections over Serial and Cellular (3G) interface. The Cisco 819HGW and Cisco 819HWD ISRs support WiFi radios (AP802H-AGN). A Wireless Local Area Network (WLAN) implements a flexible data communication system frequently augmenting rather than replacing a wired LAN within a building or campus. WLANs use radio frequency to transmit and receive data over the air, minimizing the need for wired connections. The Cisco 819HG-4G and Cisco 819G-4G support multimode 4G LTE and have embedded Sierra Wireless multimode modem.

Cisco C819 Data Networking

Part Details: C819 M2M Hardened 3.7G HSPA+ North America w/ Dual Radio FC

Need a different version of the Cisco C819 Data Networking? View all 8 configurations

MSRP: $2,300.00 Price: $1,762.34

Additional Information

Manufacturer AIDC	Cisco
Model Name	C819

Cisco C819 Specs (pdf)

General Information

Product Type: Wireless Integrated Services Router
Product Series: 800
Brand Name: Cisco
Manufacturer: Cisco Systems, Inc
Product Model: C819HGW
Product Name: C819HGW Wireless Integrated Services Router

Physical Characteristics

Height: 1.7"
Width: 7.7"
Depth: 9"
Form Factor: Desktop
Weight (Approximate): 3.40 lb

Interfaces/Ports

USB: Yes
Number of Network (RJ-45) Ports: 4
Number of Broadband (RJ-45) Ports: 1
PoE (RJ-45) Port: No
VGA: No
Network (RJ-11): No
Powerline: No
Management Port: Yes
Serial: Yes

Other

Certifications & Standards:
- Safety:
- UL 60950-1
- CAN/CSA C22.2 No. 60950-1
- EN 60950-1, 2nd edition
- CB to IEC 60950-1
- EMC:
- EN55022/CISPR22
- CFR 47 Part 15
- ICES003
- VCCI-V-3
- CISPR22
- CNS13438
- EN61000-3-2
- EN61000-3-3
- EN61000-6-1
- EN55024
- CISPR24
- EN61000-4-2
- EN61000-4-3
- EN61000-4-4
- EN61000-4-5
- EN61000-4-6
- EN61000-4-11
- EN300-386
- EN61373
- Radio:
- EN301 489-1
- EN 301 489-7
- EN301 489-24
- EN 301 908-1,
- EN 301 908-2,
- EN 301 511, 47 CFR Part 22, and 47 CFR Part 24
- IEEE Standards:
- 802.11a
- 802.11b
- 802.11g
- 802.11n
- 802.1d
- 802.1Q
- 802.1x

Wireless Specifications

Broadband Transmission Technology:
- Cellular
- Ethernet
Wireless LAN Standard: IEEE 802.11n
ISM Band: Yes
UNII Band: Yes
ISM Maximum Frequency: 2.40 GHz
UNII Maximum Frequency: 5 GHz
Cellular Data Connectivity Technology:
- HSPA+
- HSDPA
- UMTS
- EDGE
- GPRS
- HSUPA
Cellular Generation: 3.75G
Cellular Network Supported:
- WCDMA 850
- WCDMA 900
- WCDMA 1900
- WCDMA 2100
- GSM 850
- GSM 900
- GSM 1800
- GSM 1900
Antenna Type: Swivel Dipole Antenna
Features:
- Quality of Service (QoS)
- MIMO Technology
- GPS Capable
Wireless Security:
- AES 128/192/256-bit
- IEEE 802.1x
- IPS

Management & Protocols

Management:
- Web Base Management
- SNMP v1,v2,v3
- DHCP
- MIB
- VLAN
- Telnet
- CLI
- MIB II
- Cisco IOS Software Release 15.2 (4) M1 or Later
Security Features:
- IPsec
- 3DES
- NAT
- SPI
- L2TPv3
- ACL
- MAC Address Filtering

Network & Communication

Ethernet Technology: Fast Ethernet
Network Technology:
- 10/100Base-TX
- 10/100/1000Base-T
VPN Supported: Yes

Power Description

Input Voltage:
- 110 V AC
- 220 V AC
Power Source: AC Supply

Warranty

Limited Warranty: 1 Year

I/O Expansions

Expansion Slots: 2 x SIM Card

Extended Details

Cisco C819 Data Networking Part #: C819HGW+7-A-A-K9 | SKU: CIS227715
