Additional Information
| Manufacturer | Cisco |
|---|---|
| Model Name | Accessories |
| Type | No |
General Information
- Product Type: Proprietary Power Supply
- Brand Name: Cisco
- Manufacturer: Cisco Systems, Inc
- Product Name: 4000 Watt DC Power Supply
Physical Characteristics
- Weight (Approximate): 32 lb
Other
- Compatibility:
- Catalyst 6506
- Catalyst 6509
- Catalyst 6509-NEB
- Catalyst 6509-NEB-A
- Catalyst 6513
- Additional Information:
- KVA rating: 5.4 kVA maximum
- System power dissipation: 5200 W (total input power)
- DC-input current: 40 A per each DC input (three inputs)
- DC input terminal block accepts 4 AWG copper conductors
- Power supply output capacity:
- 4000 W with three inputs active
- 2700 W with two inputs active
Power Description
- Input Voltage Type: DC
- Input Voltage:
- -56 V DC
- -72 V DC
- Output Power: 4 kW
- Input Voltage Range:
- -40 V DC to -56 V DC
- -55 V DC to -72 V DC
- Output Voltage:
- 3.3 V DC
- 5 V DC
- 12 V DC
- 42 V DC
Controls/Indicators
- Status Indicators:
- Input OK
- Fan OK
- Output Fail
