Cisco Catalyst 2960 Series Switch Data Networking
Part #: WS-C3560X-48U-S | SKU: CIS229416

Cisco Catalyst 2960 Series Intelligent Ethernet Switches enable entry-level enterprise, medium-sized, and branch office networks to provide enhanced LAN services. This family of fixed-configuration, standalone devices provide desktop 10/100 Fast Ethernet and 10/100/1000 Gigabit Ethernet connectivity.

Cisco Catalyst 2960 Series Switch Data Networking

Part Details: Catalyst 3560X 48 Port UPOE IP Base

Need a different version of the Cisco Catalyst 2960 Series Switch Data Networking? View all 35 configurations

Additional Information

Manufacturer AIDC	Cisco
Model Name	Catalyst 2960 Series Switch

Cisco Catalyst 2960 Series Switch Specs (pdf)

General Information

Product Type: Ethernet Switch
Product Series: 3560-X
Brand Name: Cisco
Manufacturer: Cisco Systems, Inc
Product Model: WS-C3560X-48U-S
Product Name: Catalyst WS-C3560X-48U-S Ethernet Switch
Product Line: Catalyst

Physical Characteristics

Compatible Rack Unit: 1U
Height: 1.8"
Width: 17.5"
Depth: 19.5"
Form Factor:
- Rack-mountable
- Desktop
Weight (Approximate): 16.70 lb

Interfaces/Ports

Stack Port: Yes
Total Number of Network Ports: 48
Port/Expansion Slot Details:
- 48 x Gigabit Ethernet Network
- 1 x Expansion Slot
Token Ring Port: No
LRE Port: No
USB: Yes
Modular: Yes
Management Port: Yes
Uplink Port: No
Bypass: No
Number of UPOE (RJ-45) Ports: 48

Other

Green Compliant: Yes
Green Compliance Certificate/Authority: RoHS-5
Package Contents:
- Catalyst WS-C3560X-48U-S Ethernet Switch
- AC Power Supply
- Power Cord
- Catalyst WS-C3560X-48U-S Ethernet Switch
- AC Power Supply
- Power Cord
Certifications & Standards:
- IEEE Standards:
- 802.3at
- 802.3
- 802.3u
- 802.3z
- 802.1D
- 802.1Q
- 802.3ab
- 802.1p
- 802.3x
- 802.3ad
- 802.1w
- 802.1x
- 802.1s
- 802.1ae
- EMC:<br />
- FCC Part 15 (CFR 47) Class A
- ICES-003 Class A
- EN 55022 Class A
- CISPR 22 Class A
- AS/NZS 3548 Class A
- BSMI Class A
- VCCI Class A
- EN 55024
- EN300386
- EN 50082-1
- EN 61000-3-2
- EN 61000-3-3
- EN61000-4-2
- EN61000-4-3
- EN61000-4-4
- EN61000-4-5
- EN61000-4-6
- EN 61000-6-1
- Safety:
- UL 60950-1
- CAN/CSA-C22.2 No. 60950-1
- EN 60950-1
- IEC 60950-1
- CCC

Management & Protocols

Manageable: Yes
Management:
- Cisco Network Assistant
- CiscoWorks LAN Management Solution
- Syslog
- Telnet
- QoS
- VLAN
- DHCP
- MIB
- SNMP v1, v2c, v,3
- RMON 1, 2, 3, 9

Power Description

PoE (RJ-45) Port: No
Input Voltage:
- 110 V AC
- 220 V AC
Redundant Power Supply: Yes
Power Source: Power Supply

Media & Performance

Ethernet Technology: Gigabit Ethernet
Media Type Supported: Twisted Pair
Network Technology: 10/100/1000Base-T
Twisted Pair Cable Standard: Category 5e

Memory

Memory Technology: DRAM
Flash Memory: 64 MB
Standard Memory: 256 MB

Warranty

Limited Warranty: Lifetime

Network & Communication

Layer Supported: 2

I/O Expansions

Number of Total Expansion Slots: 1

Reliability

MTBF: 189710 Hour

Extended Details

Cisco Catalyst 2960 Series Switch Data Networking Part #: WS-C3560X-48U-S | SKU: CIS229416
