Additional Information
| Interface Options | Ethernet, Parallel, Serial (RS-232), USB |
|---|---|
| Manufacturer AIDC | CognitiveTPG |
| Max Roll Outer Diameter | 4.7 |
| Model Name | DLXi |
| Print Resolution | 203 dpi |
| Print Speed | 5 ips |
| Printer Type | Desktop |
| Printing Technology | Direct Thermal |
CognitiveTPG DLXi Specs
Technical Information
- Maximum Mono Print Speed: 5 in/s
- Peel Facility: Yes
- Maximum Print Resolution: 203 dpi
- Print Color: Monochrome
- Maximum Print Width: 2.20"
- Recommended Use: Label Print
- Features: Peel Facility
- Barcode Symbology Supported:
- Add2
- Add5
- Codabar
- Code 39
- Code 93
- Code 128-A
- Code 128-B
- Code 128-C
- D2 of 5
- I-2/5
- S2 of 5
- EAN-8
- EAN-8+
- EAN-13
- EAN-13+
- EAN 128
- Maxi Code
- MSI1
- MSI
- Plessey
- POSTNET
- UPC-A
- UPC-A+
- UCP-E
- UPC-E1
- Data Matrix
- Aztec Code
- QR Code
- RSS
- PDF-417
General Information
- Product Type: Direct Thermal Printer
- Brand Name: CognitiveTPG
- Manufacturer: Cognitive TPG
- Product Model: DLXi
- Product Name: DLXi Label Printer
Physical Characteristics
- Height: 6.1"
- Width: 4.7"
- Depth: 9.4"
- Form Factor: Desktop
- Weight (Approximate): 3.10 lb
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
- Parallel Port: Yes
Other
- Platform Supported: PC
- Package Contents:
- DLXi Label Printer
- Quick Start Guide
- USB Cable
- Power Supply
- Power Cord
- Special Serial Cable
- DLXi Label Printer
- Quick Start Guide
- USB Cable
- Power Supply
- Power Cord
- Special Serial Cable
Media Types & Handling
- Maximum Label Width: 2.40"
- Media Type:
- Black Bar
- Notch
- Gap
- Maximum Roll Diameter: 4.70"
Fonts & Emulation
- Language Emulation:
- CPL
- ZcPL
- EcPL
Memory
- Standard Memory: 16 MB
- Memory Technology: SDRAM
- Flash Memory: 8 MB
Network & Communication
- Ethernet: Yes
- Ethernet Technology: Fast Ethernet
Power Description
- Input Voltage: 24 V DC
- Power Source: Power Adapter
Warranty
- Limited Warranty: 2 Year
