CradlePoint CBR400 Products
Part #: IBR650E-SP | SKU: CRA146068

CradlePoint CBR400 Products

Part Details: CradlePoint COR IBR650E Wireless Router - 3G - 2 x Antenna - 1 x Network Port - 1 x Broadband Port - USB - Fast Ethernet - Wall Mountable

Additional Information

Manufacturer CradlePoint
Model Name CBR400

General Information

  • Product Type: Wireless Router
  • Product Series: IBR600
  • Brand Name: CradlePoint
  • Manufacturer: CradlePoint, Inc
  • Product Model: IBR650E
  • Product Name: COR IBR650E Wireless Router
  • Product Line: COR

Physical Characteristics

  • Height: 0.9"
  • Width: 4"
  • Depth: 3.3"
  • Form Factor: Wall Mountable
  • Weight (Approximate): 7.05 oz

Interfaces/Ports

  • Ethernet Port: Yes
  • Fast Ethernet Port: Yes
  • Gigabit Ethernet Port: No
  • USB: Yes
  • Number of Network (RJ-45) Ports: 1
  • Number of Broadband (RJ-45) Ports: 1
  • PoE (RJ-45) Port: No
  • VGA: No
  • Network (RJ-11): No
  • Powerline: No
  • Management Port: No
  • Serial: No

Management & Protocols

  • Management:
    • Web-based Management
    • SNMP
    • WiPipe Central Management
    • VLAN
    • DHCP
  • Security Features:
    • VPN
    • IPSec
    • PPTP
    • URL Filtering
    • Traffic Filtering
    • Port Forwarding
    • GRE Tunneling
    • SSH
    • NAT
    • L2TP
    • Port Blocking
    • Service Filtering
    • RADIUS
    • MAC Address Filtering
    • Content Filtering
    • Website Filtering
    • PPPoE
    • SPI Firewall
    • DMZ
    • MD5
    • SHA128
    • SHA256
    • SHA384
    • SHA512
    • AES
    • 3DES
    • DES
    • Intrusion Detection

Other

  • Green Compliant: Yes
  • Green Compliance Certificate/Authority:
    • WEEE
    • RoHS
  • Country of Origin: Taiwan
  • Certifications & Standards:
    • IEEE 802.3
    • IEEE 802.3u
    • IEEE 802.1q
    • RSS-102
    • PTCRB
    • RSS-129
    • RSS-132e
    • RSS-133 r1
    • FCC
    • IC
    • CE
  • System Requirements:
    • Web Browsers:
    • Firefox v2.0
    • Internet Explorer v7.0
    • Google Chrome
    • Safari v1.0
    • Operating Systems:
    • Windows 2000
    • Windows XP
    • Windows 7
    • Mac OS X
    • Linux

Wireless Specifications

  • Broadband Transmission Technology:
    • Cellular
    • Ethernet
  • ISM Band: No
  • UNII Band: No
  • Cellular Data Connectivity Technology: EVDO
  • Cellular Generation: 3G
  • Cellular Network Supported: CDMA2000 1X
  • Total Number of Antennas: 2
  • Antenna Gain: 2 dBi
  • Antenna Connector: SMA Connector
  • Features:
    • Quality of Service (QoS)
    • MIMO Technology

Power Description

  • Input Voltage: 12 V DC
  • Power Source: AC Adapter

Network & Communication

  • Ethernet Technology: Fast Ethernet
Extended Details
