Custom America Xr200 Receipt Printer

PAPER:
TYPE roll paper
WIDTH 3"
THICKNESS 0.00256"- 0.00512"
ROLL DIAMETER max. 3"
INK RIBBON Epson ERC-23, ERC-38 black, purple, black/red

SPECIFICATIONS:
EMULATION Epson TM-U200, Citizen iDP-3540, Star SP200, Verifone P900
INTERFACES RS232, parallel
DRAW PORT 2 circuits (24V, 1A max)
PRINTING METHOD 9-pin serial impact dot matrix
PRINTING SPEED 4 lines / sec
DOT DENSITY(DPI) 160
EFFECTIVE PRINTING WIDTH 2.5", 400 dots / line
PRINTING DIRECTION bi-directional
COPIES original + 2 copy
LINE SPACING none / 144"
FONT SIZE 7 x 9, 9 x 9

AUTO CUTTER:
TYPE guillotine
LIFE 500,000 cuts
PAPER THICKNESS 0.00256"- 0.00512"
CUTTING METHOD full / partial cut

PHYSICAL:
WEIGHT 3.64lb, 4.21lb w/ autocutter
DIMENSION (WxDxH) 6.88" x 8.60" x 5.20"
COLOR black, ivory

RELIABILITY:
PRINTHEAD LIFE 120,000,000 characters

ENVIRONMENTAL:
OPERATING TEMPERATURE 41 - 104?F
STORAGE TEMPERATURE -4 - 140?F
OPERATING HUMIDITY 10 - 80%
STORAGE HUMIDITY5 - 95%

SAFETY & REGULATORY APPROVALS
FCC, UL/cUL, CE-LVD, CE-EMCD, ROHS

WHAT?S IN THE BOX:
receipt printer, manual, paper

WARRANTY:
3 year Limited
