Custom America Xr510 Specs
PAPER:
TYPE thermal paper
WIDTH 1.97" - 3.25"
THICKNESS 0.00236" - 0.00354"
ROLL DIAMETER max. 3.268"
ROLL CORE INNER DIAMETER 0.49" ? 0.02"
SPECIFICATIONS:
EMULATION ESC/POS command compatible
SENSORS paper end sensor, paper low sensor
INTERFACES RS232, Parallel, USB 2.0, Ethernet
PRINTING METHOD direct thermal
PRINTING SPEED 7.9" / sec
DOT DENSITY(DPI) 180 x 180
DOT PITCH 0.00555" x 0.00555"
EFFECTIVE PRINTING WIDTH 2.835", 512 dots / line
PRINTING DIRECTION unidirectional with friction feed
AUTO CUTTER:
TYPE JamFree auto-retracting Guillotine
LIFE 1,000,000 cuts
PAPER THICKNESS 0.00236" - 0.00354"
CUTTING METHOD full / partial cut
PHYSICAL:
WEIGHT 3.53 lbs
DIMENSION (WxDxH) 6" x 7.6" x 5.8"
COLOR black
RELIABILITY:
THERMAL PRINTHEAD LIFE 62.14 miles
ENVIRONMENTAL:
OPERATING TEMPERATURE 41 - 104?F
STORAGE TEMPERATURE -4 - 140?F
OPERATING HUMIDITY 35 - 80%
STORAGE HUMIDITY 10 - 90%
SAFETY & REGULATORY APPROVALS
FCC, UL/cUL, CE-LVD, CE-EMCD, ROHS
WHAT?S IN THE BOX:
receipt printer, manual, paper, interface cable
WARRANTY:
3 year Limited
-
Custom America Xr510 Receipt Printer
Part #: XR510-US | SKU: CUS86428Custom-America XR510-US Direct Thermal Printer - Monochrome - Black - Desktop - Receipt Print - USB - Serial - 2.84" Print Width - 7.90 in/s Mono - 180 x 180 dpi - Thermal Paper - 3.25" Label Width
