Additional Information
| Interface Options | Ethernet, Parallel, Serial (RS-232), USB |
|---|---|
| Manufacturer | Datamax-O'Neil |
| Max Roll Outer Diameter | 8 |
| Model Name | H-6210 |
| Print Resolution | 203 dpi |
| Print Speed | 10 ips |
| Printer Type | Industrial |
| Printing Technology | Thermal Transfer |
| Ribbon Core Size | 1 inch |
Datamax-O'Neil H-6210 Specs
Datamax-O'Neil H-6210 Driver
Technical Information
- Maximum Mono Print Speed: 10 in/s
- Maximum Print Resolution: 203 dpi
- Print Color: Monochrome
- Maximum Print Width: 6.61"
- Recommended Use: Label Print
- Features: Real Time Clock
- Barcode Symbology Supported:
- Code 3 of 9
- UPC-A
- UPC-E
- Interleaved 2 of 5
- Industrial 2 of 5
- Standard 2 of 5
- Code 11
- Code 93
- Code 128
- EAN-8
- EAN-13
- HIBC
- Codabar
- Plessey
- UPC 2 and 5 Digit Addendums
- POSTNET
- UCC/EAN 128
- Telepen
- Planet Code
- FIM
- USPS-4 State
- Maxi Code
- PDF-417
- USD-8
- Data Matrix
- QR Code
- Codablock
- Code 16K
- Aztec Code
- TLC 39
- Micro PDF-417
- GS1 DataBar
General Information
- Product Type: Direct Thermal/Thermal Transfer Printer
- Brand Name: Datamax
- Manufacturer: Datamax-O'Neil
- Product Model: H-6210
- Product Name: H-Class H-6210 Label Printer
- Product Line: H-Class
Physical Characteristics
- Height: 13"
- Width: 15"
- Depth: 18.9"
- Form Factor: Desktop
- Weight (Approximate): 47 lb
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
- Parallel Port: Yes
Media Types & Handling
- Maximum Label Width: 6.70"
- Media Type:
- Roll Fed
- Fanfold
- Die-cut Label
- Continuous Label
- Perforated Label
- Continuous Tag
- Ticket Stock
- Media Thickness: 10 mil
- Media Sensor:
- Reflective Media Sensor
- Transmissive Media Sensor
- Label Core Size: 3"
- Ribbon Core Size: 1"
- Maximum Roll Diameter: 8"
Fonts & Emulation
- Language Emulation:
- PLZ
- PLI
- PLB
Network & Communication
- Ethernet: Yes
- Ethernet Technology: Fast Ethernet
Memory
- Standard Memory: 16 MB
- Flash Memory: 8 MB
Display & Graphics
- Display Screen Type: LCD
Other
- Platform Supported: PC
Power Description
- Power Source: AC Supply
