Additional Information
| Interface Options | Parallel, USB |
|---|---|
| Manufacturer AIDC | Datamax-O'Neil |
| Max Roll Outer Diameter | 5 |
| Model Name | E-4205e |
| Print Resolution | 203 dpi |
| Print Speed | 5 ips |
| Printer Type | Desktop |
| Printing Technology | Thermal Transfer |
Datamax-O'Neil E-4205e Specs
Technical Information
- Maximum Mono Print Speed: 5 in/s
- Maximum Print Resolution: 203 dpi
- Print Color: Monochrome
- Maximum Print Width: 4.25"
- Recommended Use: Label Print
- Barcode Symbology Supported:
- Code 3 of 9
- UPC-A
- UPC-E
- Interleaved 2 of 5
- Code 128
- EAN-8
- EAN-13
- HIBC
- Codabar
- Plessey
- UPC 2 and 5 Digit Extension
- Code 93
- POSTNET
- UCC/EAN 128
- Telepen
- Maxi Code
- PDF-417
- USD-8
- Data Matrix
- QR Code
- Aztec Code
- TLC 39
- Micro PDF-417
General Information
- Product Type: Direct Thermal/Thermal Transfer Printer
- Brand Name: Datamax-O'Neil
- Manufacturer: Datamax-O'Neil
- Product Model: Mark II E-4205e
- Product Name: E-Class Mark II E-4205E Thermal Label Printer
- Product Line: E-Class
Physical Characteristics
- Height: 7.1"
- Width: 8.8"
- Depth: 10"
- Form Factor: Desktop
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
- Parallel Port: Yes
Media Types & Handling
- Maximum Label Width: 4.30"
- Media Type:
- Roll Fed
- Fanfold
- Die-cut Label
- Continuous Label
- Perforated Label
- Continuous Tag
- Ticket Stock
- Media Thickness: 10 mil
- Media Sensor:
- Transmissive Media Sensor
- Reflective Media Sensor
- Label Taken Sensor
- Label Core Size: 1"
- Ribbon Core Size: 0.50"
- Maximum Roll Diameter: 5"
Other
- Platform Supported: PC
- Additional Information:
- 3-button, 3-LED Control Panel
- Easy Access Cantilevered Printhead
- Clear See-Through Media Window
- Flash Upgradeable Firmware
Memory
- Standard Memory: 16 MB
- Memory Technology: SDRAM
- Flash Memory: 4 MB
Warranty
- Limited Warranty: 1 Year
