Additional Information
| Connectivity | Cordless |
|---|---|
| Manufacturer AIDC | Hand Held |
| Model Name | ImageTeam 3875 |
| Scanner Capability | 1D |
Hand Held ImageTeam 3875 Specs
Technical Information
- Form Factor: Handheld Scanner
- Resolution: 6.5 mil(s)
- Symbologies Supported:
- UPC-A
- UPC-E
- EAN-13
- EAN-8
- RSS
- Code 39
- Code 128
- UCC/EAN 128
- ISBT 128
- Codabar
- Code 11
- Code 93
- Interleaved 2 of 5
- Straight 2 of 5
- Matrix 2 of 5
- Telepen
- Scanner Type: Imager
- Scan Rate: 270 Scans/sec
- Interface Options: PS/2 Keyboard Wedge
- Interface Connectivity: Cordless
- Cordless Range: 30m
- Depth of Field:
- 3 - 8.5"@6.5mils
- 0.8 - 14"@13mils
- 0.8 - 18"@15mils
General Information
- Manufacturer:
- Product Line: IMAGETEAM
- Product Name: IMAGETEAM 3875 Interactive Cordless Barcode Scanner
Physical Characteristics
- Weight: 18.5 oz
Agency Approvals
- Agency Approvals:
- FCC Part 15 Class B
- SOR 88/475 Class B
- EN 55022 (CISPR22) Class B
- EN 61000-3-2 & -3
- ETS 300 826
- EMC 89/336/EEC
- EN 50082-1:1992
- IEC 801-2:1991
- IEC 801-3:1984
- IEC 801-4:1988
- UL listed
- C22.2 No 950/UL 1950
- cUL Listed
- TUV Rheinland GS Licensed EN 60950 (IEC950)
- AS/NZS 3548
- FCC Part 15.249
- RSS 210
- ETS 300 328
Other
- Package Contents:
- IMAGETEAM 3875 Interactive Cordless Barcode Scannerr
- PS/2 Keyboard Wedge Cable (42205021-01)
- Keypad
- Display
- Charge Pack
- Quick Start Guide
- Cordless Base Station(part # 2070-5X)
- System Manual
- Cables Included: Keyboard Wedge
Environmental Conditions
- Temperature:
- 32°F (0°C) to 122°F (50°C) Operating
- -22°F (-30°C) to 122°F (50°C) Storage
- Humidity: 5 to 95%
Warranty
- Manufacturer Warranty: 3 Year(s)
