Form Factor: | Purpose-built, compact, handle-style mobile computer |
Operating System: | Microsoft Windows Mobile 5.0 |
Development Environment: | Hand Held Products Dolphin SDK for Visual Studio 2005 - supports C/C++, C# and Visual Basic development on Visual Studio 2005 |
Third Party Software: | SOTI MobiControl (remote device management), PowerNet Terminal Emulation (TNVT, 3270, 5250), and ITScriptNet |
CPU: | Intel PXA 270 520 MHz |
Memory: | 64MB X 64MB & 128 MB RAM X 128 MB Flash memory options available |
Display: | 3.5 in. 1/4 VGA 240 X 320 TFT color display with hard-coat industrial touch panel |
Imager/Scanner: | 5100SR/SF VGA Area Imagers with bright green LED aimer 5300SR/SF VGA Area Imagers with High-Vis aiming pattern 5300HD VGA Area Imagers with High-Vis aiming pattern HP (High Performance) Laser scanner (future option) LR (Long Range) Laser scanner (future option) ALR (Advanced Long Range) Laser scanner (future option) |
Keyboards: | 24-key calculator-style numeric with scrolling alpha 38-key calculator-style numeric with full alpha |
Communications: | 100K duty-cycle plugable/dockable RS232/USB connector, IrDA, Audio beeper |
Battery: | Main: Lithium-ion 7.4V, 14.1 Watt-hour, hot-swappable battery
pack Backup: Internal 3.6V nickel metal hydride (NiMH) battery saves RAM data for 30-minutes during main battery change |
Run Time (estimated): | WLAN: 10+ hours at 1 scan/6 sec, 1 data package logged every scan, 802.11b/g continuous connection, & display backlight on full |
Stand-by Time: | Device suspend mode: 8 days minimum |
Charging: | 9.5V AC input through handle charge port or USB/Serial connector, four hours recharge |
Charging Peripherals: | AC wall adapter, Charge/Communication Cable, single bay Home Base, 4 bay Charge Base, battery Quad Charger |
WLAN Standard: | 802.11b/g, Wi-Fi Certified |
WLAN Security: | WEP, WPA Personal/Enterprise, WPA2 Personal/Enterprise, EAP-TLS, TTLS, LEAP, PEAP, Cisco CCX compliant (pending) |
WPAN (optional): | Bluetooth class 2, version 1.2 (optional feature) |
Co-Located/Operational: | Two radios: WLAN/WPAN |
Operating Temperature: | Standard configuration is 14°-122°F / -10°-50°C nominal; -4°
(-20°C) with reduced runtime Optional Bluetooth configuration is 32°-104°F / 0°-40°C |
Construction: | Magnesium alloy internal chassis with component shock
mounts Engineering-grade polycarbonate outer housing with integrated rubber over-molded handle |
Structural: | 5 ft. (1.5m) multiple drops to concrete, all axis, across
operating temperature range Exceeds 2000 3 ft. (1m) tumbles |
Environmental: | IP64 rated for blown dust/water intrusion |
Dimensions: | Main housing: 7.1 in. Long X 3.3 in. Wide X 1.4 in. Deep (18 cm
Long X 8.4 cm Wide X 3.6 cm Deep) Handle: 4.6 in. Long X 1.6 in. Wide X 1 in. Deep (12 cm Long X 4.1 cm Wide x 2.5 cm Deep) |
Weight: | Approximately 22 oz/684g |
Standard: | 2 years |
