Additional Information
| Display Type | LCD |
|---|---|
| Interface Options | USB, USB Host |
| Manufacturer AIDC | Honeywell |
| Max Roll Outer Diameter | 5 |
| Model Name | EasyCoder PC23d |
| Print Resolution | 300 dpi |
| Print Speed | 6 ips |
| Printer Type | Desktop |
| Printing Technology | Direct Thermal |
Honeywell EasyCoder PC23d Specs
Technical Information
- Maximum Mono Print Speed: 6 in/s
- Maximum Print Resolution: 300 dpi
- Print Color: Monochrome
- Maximum Print Width: 2.10"
- Recommended Use: Label Print
- Features: Real Time Clock
- Barcode Symbology Supported:
- Aztec Code
- Code 16K
- Code 49
- Data Matrix
- EAN-13
- EAN-8
- EAN.UCC 128
- Grid Matrix
- HIBC Code 128
- HIBC Code 39
- Maxi Code
- MSI
- PDF-417
- Micro PDF-417
- Planet Code
- Plessey
- POSTNET
- QR Code
- RSS-14
General Information
- Product Type: Direct Thermal Printer
- Product Series: PC
- Brand Name: Intermec
- Manufacturer: Intermec Technologies Corporation
- Product Model: PC23d
- Product Name: PC23d Desktop Printer
Physical Characteristics
- Height: 6.9"
- Width: 4.9"
- Depth: 8.5"
- Form Factor: Desktop
- Weight (Approximate): 3.20 lb
Interfaces/Ports
- USB: Yes
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority:
- RoHS
- ENERGY STAR
- Platform Supported: PC
- Package Contents:
- PC23d Desktop Printer
- Software, Driver & Documentation CD
- USB Cable
- Power Adapter
- Power Cord
- Handy QuickGuide
- PC23d Desktop Printer
- Software, Driver & Documentation CD
- USB Cable
- Power Adapter
- Power Cord
- Handy QuickGuide
- Certifications & Standards:
- CE
- FCC Class A
- C-UL-US
- UL
- GS
- TUVGS
- BSMI
- D Mark
- cUL
- CCC (China)
- KCC (South Korea)
- C-TICK (Australia/NZ)
- UL 60950-1
- EN 60950-1
- CE marked
- NYCE Certified
- NOM 19
- IEC 60950-1
- USA FCC Title 47
- Part 15
- Subpart A
- Class B
- Europe EMC Directive (EN55022 Class B + EN55024)
- CISPR22
Media Types & Handling
- Maximum Label Width: 2.40"
- Maximum Label Length: 35"
- Media Type:
- Tag
- Linerless
- Self Adhesive Label
- Continuous Paper
- Floodcoat
- Non-adhesive Tag
- Media Sensor: Transmissive Media Sensor
- Label Core Size: 1.50"
- Maximum Roll Diameter: 5"
Fonts & Emulation
- Language Emulation:
- IPL
- Fingerprint
- DSim
- ZSim
- XML
- E-Sim
Memory
- Standard Memory: 128 MB
- Memory Technology: DDR2 SDRAM
- Flash Memory: 128 MB
Display & Graphics
- Display Screen Type: LCD
- Screen Size: 2.4"
Power Description
- Input Voltage: 24 V DC
- Power Source: Power Adapter
Warranty
- Limited Warranty: 1 Year
