| Included Features | Media Hanger |
|---|---|
| Interface Options | Ethernet, Serial (RS-232) |
| Manufacturer AIDC | Intermec |
| Max Roll Outer Diameter | 6, 8.4 |
| Model Name | EasyCoder PF2i |
| Print Resolution | 203 dpi |
| Print Speed | 8 ips |
| Printer Type | Industrial |
| Printing Technology | Direct Thermal |
Intermec EasyCoder PF2i Specs
Technical Information
- Maximum Mono Print Speed: 8 in/s
- Maximum Print Resolution: 203 dpi
- Print Color: Monochrome
- Maximum Print Width: 2.20"
- Recommended Use: Label Print
- Barcode Symbology Supported:
- Codabar
- Code 11
- Code 39
- Code 93
- Code 128
- Code 128-A
- Code 128-C
- DUN-14/16
- EAN-8
- EAN-13
- EAN 128
- EAN-128 Subset A
- EAN-128 Subset C
- Industrial 2 of 5
- Interleaved 2 of 5
- Interleaved 2 of 5 A
- Matrix 25
- POSTNET
- Straight 2 of 5
- Two-character Supplemental Code
- UCC 128
- UPC-5 Digits Add-on
- UPC-A
- UPC-D1
- UPC-D2
- UPC-D3
- UPC-D4
- UPC-D5
- UPC-E
- Code 16K
- Code 49
- Data Matrix
- Maxi Code
- MSI PLESSEY
- PDF-417
- Plessey
- QR Code
- Micro PDF-417
General Information
- Product Type: Direct Thermal Printer
- Product Series: PF
- Brand Name: Intermec
- Manufacturer: Intermec Technologies Corporation
- Product Model: PF2i
- Product Name: EasyCoder PF2i Thermal Label Printer
- Product Line: EasyCoder
Physical Characteristics
- Height: 8.1"
- Width: 7.6"
- Depth: 15.6"
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
Media Types & Handling
- Maximum Label Width: 2.36"
- Media Type:
- Roll Fed
- Die-cut Label
- Continuous Form
- Fanfold
- Tag
- Ticket
- Direct Thermal Label
- Thermal Transfer Label
- Media Thickness: 7.50 mil
- Label Core Size: 3"
- Maximum Roll Diameter: 6"
Memory
- Standard Memory: 32 MB
- Memory Technology: SDRAM
- Flash Memory: 16 MB
Power Description
- Input Voltage:
- 110 V AC
- 220 V AC
Network & Communication
- Ethernet: Yes
- Ethernet Technology: Fast Ethernet
Warranty
- Limited Warranty: 1 Year
Other
- Platform Supported: PC
