| Interface Options | Ethernet, Serial (RS-232), USB |
|---|---|
| Manufacturer | Intermec |
| Max Roll Outer Diameter | 8.38 |
| Model Name | PM43 |
| Print Resolution | 300 dpi |
| Print Speed | 12 ips |
| Printer Type | Industrial |
| Printing Technology | Thermal Transfer |
| Ribbon Core Size | 1 inch |
Intermec PM43 Specs
Intermec PM43 Driver
Technical Information
- Maximum Mono Print Speed: 12 in/s
- Maximum Print Resolution: 300 dpi
- Print Color: Monochrome
- Maximum Print Width: 4.17"
- Recommended Use: Label Print
- Barcode Symbology Supported:
- UPC/EAN Shipping Container
- UCC/EAN 128 Serial Shipping Container
- LOGMARS
- POSTNET
- HIBCC
- ISBT-128
- GM1724
General Information
- Product Type: Direct Thermal/Thermal Transfer Printer
- Product Series: PM
- Brand Name: Intermec
- Manufacturer: Intermec Technologies Corporation
- Product Model: PM43
- Product Name: PM43 Mid-Range Printer
Physical Characteristics
- Height: 11.6"
- Width: 11.2"
- Depth: 19"
- Form Factor: Desktop
- Weight (Approximate): 34.88 lb
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
Media Types & Handling
- Maximum Label Width: 4.50"
- Media Type:
- Label
- Tag
- Linered Label
- Linerless
- Roll Fed
- Fanfold
- Gap
- Notch
- Black Mark
- Continuous Label
- Media Thickness: 10.40 mil
- Media Sensor: Transmissive Media Sensor
- Label Core Size: 3"
- Ribbon Core Size: 1"
- Maximum Roll Diameter: 8.38"
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority:
- ENERGY STAR
- RoHS
- Platform Supported: PC
- Certifications & Standards:
- PFC Regulation: IEC320/C14
- CE (EN55022 Class A)
- FCC Class A
- UL/cUL
- C-Tick
- D Mark
- CCC
Power Description
- Input Voltage:
- 110 V AC
- 220 V AC
- Standby Power Consumption: 9 W
- Maximum Power Consumption: 300 W
- Power Source: AC Supply
Fonts & Emulation
- Language Emulation:
- Fingerprint
- IPL
- ZSim
- DSim
- XML
Memory
- Standard Memory: 128 MB
- Memory Technology: SDRAM
- Flash Memory: 128 MB
Network & Communication
- Ethernet: Yes
- Ethernet Technology: Fast Ethernet
Display & Graphics
- Touchscreen: Yes
Warranty
- Limited Warranty: 1 Year
