Juniper Networks SSG5 Data Networking
Part #: SSG-5-SH-W-US | SKU: JUN61144

The Juniper SSG5 Secure Services Gateways are purpose-built security appliances that deliver a perfect blend of performance, security, routing and LAN/WAN connectivity for small branch offices, fixed telecommuters and small standalone business deployments. Traffic flowing in and out of the branch office or business is protected from worms, spyware, trojans, and malware by a complete set of Unified Threat Management security features that include stateful firewall, IPsec VPN, intrusion prevention system (IPS), antivirus (includes antispyware, anti-adware, antiphishing), antispam and Web filtering.

Juniper Networks SSG5 Data Networking

Part Details: SSG5, Security Services Gateway 5 (with Serial Backup, Wireless 802.11)

Need a different version of the Juniper Networks SSG5 Data Networking? View all 7 configurations

Additional Information

Manufacturer	Juniper Networks
Model Name	SSG5

Juniper Networks SSG5 Specs (pdf)

Technical Information

Encryption Standard:
- 3DES (168-bit)
- DES
- AES
Features: PAT
Firewall Protection:
- Worm Scanning
- Trojan Horse
- Malware Protection
- Antivirus
- Anti-spyware
- Anti-phishing
- Anti-spam
- Web Content Filtering
- Deep Inspection Firewall
- Denial of Service (DoS)
- Distributed Denial of Service (DDoS)
- TCP Reassembly for Fragmented Packet Protection
- Malformed Packet Protection
- Protocol Anomaly Detection
- Stateful Protocol Signature
- URL Filtering
- Replay Attack Prevention
Virtualization:
- 4000 x Concurrent Session
- 2800 x Concurrent Session
- 200 x Policies
- 25 x Concurrent VPN Tunnel
- 10 x Tunnel Interface
- 8 x Security Zone
- 10 x Authenticated User
- 4000 x Concurrent Session
- 2800 x Concurrent Session
- 200 x Policies
- 25 x Concurrent VPN Tunnel
- 10 x Tunnel Interface
- 8 x Security Zone
- 10 x Authenticated User

General Information

Product Type: Network Security/Firewall Appliance
Product Series: SSG
Brand Name: Juniper
Manufacturer: Juniper Networks, Inc
Product Model: SSG 5
Product Name: Secure Services Gateway 5

Physical Characteristics

Height: 1.6"
Width: 8.8"
Depth: 5.6"
Form Factor: Rack-mountable
Weight (Approximate): 2.10 lb

Interfaces/Ports

Total Number of Ports: 8

Other

Certifications & Standards:
- Wi-Fi
- Safety Certifications:
- CSA
- CB
- EMC Certifications:
- FCC Class B
- CE Class B
- A-Tick
- VCCI class B
Additional Information:
- Perfect forward secrecy (DH Groups)
- Users supported: Unrestricted
- VoIP Security:
- H.323. ALG
- SIP ALG
- SCCP ALG
- MGCP ALG
- NAT for SIP, H.323, MGCP, SCCP

Power Description

Input Voltage:
- 110 V AC
- 220 V AC
Power Source: Power Supply

Network & Communication

Network Standard: 10/100Base-TX
Ethernet Technology: Ethernet

Wireless Specifications

Wireless LAN Standard: IEEE 802.11a/b/g
Number of Antennas: 2

Extended Details
