| Manufacturer AIDC | Motorola |
|---|---|
| Model Name | AP 8232 |
| Wireless Type | Wi-Fi, Wi-Fi 5: 802.11ac |
Motorola AP 8232 Specs
Technical Information
- Wireless LAN Standard: IEEE 802.11ac
- ISM Band: Yes
- UNII Band: Yes
- ISM Minimum Frequency: 2.41 GHz
- UNII Minimum Frequency: 5.18 GHz
- Wireless Transmission Speed: 1.27 Gbps
- ISM Maximum Frequency: 2.47 GHz
- UNII Maximum Frequency: 5.83 GHz
- Antenna Connector: RP-SMA Connector
- Features:
- Quality of Service (QoS)
- MIMO Technology
- Wireless Security:
- WPA2
- WPA
General Information
- Product Type: Wireless Access Point
- Brand Name: Motorola
- Manufacturer: Motorola, Inc
- Product Model: AP 8232
- Product Name: AP 8232 802.11ac Access Point
Physical Characteristics
- Height: 1.8"
- Width: 6"
- Depth: 9"
- Form Factor:
- Wall Mountable
- Ceiling Mountable
- Weight (Approximate): 3.30 lb
Interfaces/Ports
- Ethernet Port: Yes
- Fast Ethernet Port: Yes
- Gigabit Ethernet Port: Yes
- 10Gigabit Ethernet Port: No
- Number of Network (RJ-45) Ports: 2
- PoE (RJ-45) Port: Yes
- USB: Yes
- HDMI: No
- VGA: No
- Audio Line Out: No
- Serial Port: No
- Network (RJ-11): No
- Management Port: Yes
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority: RoHS
- Certifications & Standards:
- Safety:
- UL
- cUL
- 60950-1
- IEC
- EN60950-1
- UL2043
- Radio Approvals:
- FCC (USA)
- EU
- TELEC
- IEEE Standards:
- 802.11a
- 802.11b
- 802.11g
- 802.11n
- 802.11ac
- 802.11d
- 802.11i
- 802.1p
Power Description
- Power Source:
- AC Adapter
- PoE
