Additional Information
| Form Factor | Handheld |
|---|---|
| Manufacturer | Motorola |
| Model Name | DS4208 |
| Scanner Capability | 1D |
| Scanner Type | Imager |
Motorola DS4208 Specs
Technical Information
- Barcode Dimension:
- 1D
- 2D
- Scan Pattern: Omni-directional
- Connectivity Technology: Cable
- Image Sensor: Imager
- Barcode Symbology Supported:
- 1D:
- UPC/EAN
- UPC/EAN with supplementals
- Bookland EAN
- ISSN
- UCC Coupon Extended Code
- Code 128
- GS1-128
- ISBT 128
- Code 39
- Code 39 Full ASCII
- Trioptic Code 39
- Code 32
- Code 93
- Code 11
- Matrix 2 of 5
- Interleaved 2 of 5
- Discrete 2 of 5
- Codabar
- MSI
- Chinese 2 of 5
- GS1 DataBar Variants
- Korean 3 of 5
- ISBT Concat
- 2D:
- PDF417
- MicroPDF417
- Composite Codes
- TL C-39
- Data Matrix
- Maxicode
- QR Code
- MicroQR
- Aztec
- Postal:
- Australian Post
- US PLANET
- Royal Mail 4 State Customer
- US POSTNET
- KIX Code (Dutch)
- UK Postal
- Japan Post
- UPU 4 State Postal FICS (Post US4)
- USPS 4 State Postal (Post US3)
- 1D:
- UPC/EAN
- UPC/EAN with supplementals
- Bookland EAN
- ISSN
- UCC Coupon Extended Code
- Code 128
- GS1-128
- ISBT 128
- Code 39
- Code 39 Full ASCII
- Trioptic Code 39
- Code 32
- Code 93
- Code 11
- Matrix 2 of 5
- Interleaved 2 of 5
- Discrete 2 of 5
- Codabar
- MSI
- Chinese 2 of 5
- GS1 DataBar Variants
- Korean 3 of 5
- ISBT Concat
- 2D:
- PDF417
- MicroPDF417
- Composite Codes
- TL C-39
- Data Matrix
- Maxicode
- QR Code
- MicroQR
- Aztec
- Postal:
- Australian Post
- US PLANET
- Royal Mail 4 State Customer
- US POSTNET
- KIX Code (Dutch)
- UK Postal
- Japan Post
- UPU 4 State Postal FICS (Post US4)
- USPS 4 State Postal (Post US3)
- Maximum Scan Resolution: 5 mil
- Depth of Field:
- 0.20" - 6.80"@5 mil - Code 39
- 0 mil - 12.70"@10 mil - 80% UPCA
- 0.30" - 15.20"@13 mil - 100% UPCA
- 1.50" - 4.30"@5 mil - PDF 417
- 0.80" - 6"@6.60 mil - PDF 417
- 0.40" - 7.20"@10 mil - Data Matrix
General Information
- Product Type: Handheld Barcode Scanner
- Brand Name: Motorola
- Manufacturer: Motorola, Inc
- Product Model: DS4208
- Product Name: DS4208 General Purpose Handheld 2D Imager
Physical Characteristics
- Height: 6.7"
- Width: 2.7"
- Depth: 3.7"
- Color: Twilight Black
- Weight (Approximate): 6.10 oz
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority: RoHS
Warranty
- Limited Warranty: 5 Year
Recommended Accessories for Model: Motorola DS4208 Barcode Scanner
-
Zebra CBA-R02-C09PAR Cables, Connectors, and Adapters
Part #: CBA-R02-C09PAR | SKU: ZEB20870Cables - Connectors - and Adapters - Zebra - Cable - RS232 - DB9 Female Connector - 9' (2.8M) Coiled - TXD On 2MSRP: $54.07 Price: $38.27 -
Zebra CBA-U27-S09EAR Cables, Connectors, and Adapters
Part #: CBA-U27-S09EAR | SKU: ZEB129643Cables - Connectors - and Adapters - Zebra - Cable - Shielded USB - Power Plus Connector - 9' (2.8M) - Straight - EasMSRP: $130.06 Price: $99.66 -
Zebra CBA-R03-C12PAR Cables, Connectors, and Adapters
Part #: CBA-R03-C12PAR | SKU: ZEB29338Cables - Connectors - and Adapters - Zebra - Cable - RS232 - DB9 Female Connector - 12' (3.6M) Coiled - TXD On 2MSRP: $83.30 Price: $59.69 -
Zebra CBA-R09-C09ZAR Cables, Connectors, and Adapters
Part #: CBA-R09-C09ZAR | SKU: ZEB30846Cables - Connectors - and Adapters - Zebra - Cable - RS232 - 9' (2.8M) Coiled - Nixdorf Beetle - 5V Direct PowerMSRP: $61.37 Price: $43.45 -
Zebra CBA-R28-C09ZAR Cables, Connectors, and Adapters
Part #: CBA-R28-C09ZAR | SKU: ZEB26298Cables - Connectors - and Adapters - Zebra - Cable - RS232 - 9' (2.8M) Coiled - Verifone RubyPrice: $56.99
Recommended Warranties for Model: Motorola DS4208 Barcode Scanner
-
Zebra Zebra OneCare Essential Service Contract
Part #: Z1BE-DS4208-1000 | SKU: ZEB463553Service Contracts - Motorola Zebra OneCare Essential - DS4208 - Purchased 30 Days Or More Of Hardware - 1 Year - Non-Comprehensive - Standard Logistics - DashboardPrice: $30.87 -
Zebra Zebra OneCare Select Service Contract
Part #: SSS-DS4208-50 | SKU: ZEB370102Zebra OneCare Select. Includes Comprehensive Coverage. Check datasheet for regional availability.
