Additional Information
| Display Resolution | 320 x 240 |
|---|---|
| IP Rating | IP64 |
| Interface Options | Bluetooth, Wi-Fi |
| Manufacturer | Motorola |
| Model Name | MC55A0 |
| Operating System | Windows Mobile 6.5 |
| Operating Temperature | 14 F - 122 F (-10 C - 50 C) |
| Processor | Marvell PXA320 (806 MHz) |
| RAM Memory | 256 MB |
| Scanner Capability | 2D |
| Scanner Type | Imager |
| Style | Phone-size |
Motorola MC55A0 Specs
Technical Information
- Connectivity Technology: Wireless
- Image Sensor: Imager
- Electrostatic Discharge (ESD):
- +/-15 kV DC Air Discharge
- +/-8 kV DC Contact Discharge
- Drop Specification: 72" To Concrete
General Information
- Product Type: Handheld Terminal
- Brand Name: Motorola
- Manufacturer: Motorola, Inc
- Product Model: MC55A0
- Product Name: MC55A0 Handheld Terminal
Physical Characteristics
- Height: 5.8"
- Width: 3"
- Depth: 1.1"
- Weight (Approximate): 11.11 oz
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority: RoHS
- Package Contents:
- MC55A0 Handheld Terminal
- Li-Ion Battery
- MC55A0 Handheld Terminal
- Li-Ion Battery
- Certifications & Standards:
- Electrical Safety:
- Certified to UL/cUL 60950-1, IE C/EN60950-1
- WLAN and Bluetooth (PAN):
- USA:FCC Part 15.247, 15.407
- Canada:RSS-210, RSS 310
- RF Exposure:
- USA:FCC Part 2, FCC OET Bulletin 65, Supplement C
- Canada: RSS-102
- EMI/RFI:
- North America: FCC Part 15, Class B
- Canada: ICES 003 Class B
- Laser Safety:
- IE C/Class 2/FDA ll in accordance with IE C60825-1/EN 60825-1
Network & Communication
- Bluetooth: Yes
- Wireless LAN: Yes
- Antenna Form Factor: Internal
- Network Band: Tri Band
- Wireless LAN Standard: IEEE 802.11a/b/g
- Wireless Security:
- WPA2
- WEP (40 or 128 bit)
- TKIP
- TLS
- TTLS (MS-CHAP)
- TTLS (MS-CHAP v2)
- TTLS (CHAP)
- TTLS-MD5
- TTLS-PAP
- PEAP-TLS
- PEAP (MS-CHAP v2)
- AES
- LEAP
- CCXv4 certified
- FIPS 140-2 certified
Display & Graphics
- Display Screen Type: LCD
- Screen Mode: VGA
- Screen Size: 3.5"
- Display Color: Color
Battery Information
- Battery Capacity: 2400 mAh
- Battery Included: Yes
- Battery Chemistry: Lithium Ion (Li-Ion)
Processor & Chipset
- Processor Manufacturer: Marvell
- Processor Speed: 806 MHz
- Processor Type: XScale
Memory
- Flash Memory: 1 GB
- Standard Memory: 256 MB
Touchscreen Information
- Touchscreen: Yes
Warranty
- Limited Warranty: 12 Month
Software
- Operating System: Windows Mobile 6.5 Classic
Keyboard/Keypad
- Keyboard Layout: QWERTY
