Rugged for superior reliability in nearly any
Built to handle the constant pounding of material handling equipment inside and outside the four walls, with IP66 sealing, an IEC 60721-3-5M3 rating for shock and vibration that exceeds military standards (MIL-STD-810F), sealed connectors and more.
Backwards compatibility for cost-effective
Use the same mounts, accessories and applications you have today for your prior Zebra vehicle mount mobile computers, allowing you to cost-consciously upgrade to the latest technologies to improve productivity; customer service and satisfaction.
A tough, reliable touchscreen display for indoor and
The automotive-grade 640 NIT ultra bright display is easy to read, even in bright sunlight; the 5-wire touchscreen is the most accurate and reliable touchscreen technology available.
Maximize uptime and minimize total cost of ownership
with field serviceability
Replace the two elements that are most vulnerable to damage in minutes, right in your facility — the keyboard and touchscreen — no need to send to a service depot.
Flexible wireless connectivity options
Choose the wireless technology that best serves your environmental needs and your budget: 802.11a/b/g/n Wi-Fi only for compatibility with virtually any wireless LAN and plenty of bandwidth to support any application or combined Wi-Fi and Narrowband digital wireless for simple data transactions in expansive outdoor areas such as seaports, rail yards, airports and expansive outdoor yards in manufacturing plants.
8 in. color; 800 x 480; brightness 640 NIT; LED backlight; passive stylus or finger operation
Display Defroster (VH10f model): Heated touchscreen evaporates external condensation when moving out and in freezers
Quick release mount; standard RAM mounts; adapters for legacy mounts, heavy duty mount, cantilever mount
Optional UPS Battery: Optional internal 5000 mAh rechargeable battery for operation during power loss/brown out provides up to 15 minutes session persistence during forklift battery swap.
Integrated full alpha numeric keyboard with 67 keys; QWERTY and AZERTY; 12 direct function keys; LED; backlight
10.87 in. W x 9.37 in. H x 3.54 in. D (276 mm L x 238 mm W x 90 mm D)
Internal or external 2.4 GHz and 5 GHz antennas
Rugged 5-wire technology; optional heater
8.1 lbs / 3.66 kg (includes integrated UPS battery)
Standard 5 min super capacitor backup; one week real-time clock backup
Internal power supply 12-48V Nominal, designed for forklift power
WLAN and Bluetooth
USA: FCC Part 15.247, 15.407; Canada: RSS-210; EU: EN 300 328, EN 301 893
UL/cUL/IEC/EN 60950-1 Indoor use
North America: FCC Part 15, Class B; Canada: ICES 003 Class B; EU: EN55022, EN 301 489-1, EN 301 489-17
Windows(R) CE 6.0
TI OMAP3, 800 MHz
I/O interfaces included
Two USB host ports (one on the top, one on the bottom); One powered USB host port with 12V/1.5A; One 3.5 mm audio jack; Two full function UART RS-232 with 5V/1000mA for external device
512MB RAM/1 GB Flash
TekTerm, Wavelink, Stay-Linked, Naurtech
High volume 93dBA beeper; optional push-to-talk speaker/microphone
Motion (accelerometer)*; temperature, ignition
*Narrowband models do not support Motion Sensor (accelerometer).
MIL STD810G, Method 505.5, Procedure II
-22° F to +122° F/ -30° C to +50° C
-22° to 140° F/-30° to 60° C
IEC 60721-3-5M3; MIL-STD 810G; Method 516.6, Procedure 1 – Functional
48 hours of 5% solution at 35° C
Electrostatic discharge (ESD)
±15kV air discharge, ±8kV direct discharge
5% to 95% RH condensing with internal heating
-22° to 122° F/-30° to 50° C
Wireless data communications
UHF bands: 403 – 470 MHz; Channel Spacing: 12.5 - 25 kHz; RF power: 500 - 1,000mW; Transmission speed: 4.8/9.6 kbps @ 12.5 kHz, 9.6/19.2 kpbs @ 25 kHz
WPAN: Bluetooth® V2.0 + EDR
