Navigation
Additional Information
| Interface Options | Ethernet |
|---|---|
| Manufacturer AIDC | Printronix |
| Max Roll Outer Diameter | 8 |
| Model Name | T5306 |
| Print Resolution | 300 dpi, 305 dpi |
| Print Speed | 8 ips |
| Printer Type | Industrial |
| Printing Technology | Thermal Transfer |
Printronix T5306 Specs
Technical Information
- Maximum Mono Print Speed: 8 in/s
- Maximum Print Resolution: 300 dpi
- Print Color: Monochrome
- Maximum Print Width: 6.60"
- Recommended Use: Label Print
- Barcode Symbology Supported:
- Australia Post
- Aztec Code
- BC35
- BC412
- Codabar
- Code 11
- Code 35
- Code 39
- Code 93
- Code 128-A
- Code 128-B
- Code 128-C
- Data Matrix
- EAN-8
- EAN-13
- FIM
- 125 German
- Interleaved 2 of 5
- ITF-14
- Matrix
- Maxi Code
- MSI
- PDF-417
- Planet Code
- Plessey
- POSTNET
- PostBar
- ROYALBAR
- RSS-14
- Telepen
- UCC/EAN 128
- UPC-A
- UPC-E
- UPC-E0
- UPCSHIP
- UPS11
General Information
- Product Type: Direct Thermal/Thermal Transfer Printer
- Product Series: T5000r
- Brand Name: Printronix
- Manufacturer: Printronix, Inc
- Product Model: T5306r
- Product Name: T5306r Thermal Label Printer
- Product Line: ThermaLine
Physical Characteristics
- Height: 13"
- Width: 13.4"
- Depth: 20.5"
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
- Parallel Port: Yes
Media Types & Handling
- Maximum Label Width: 6.80"
- Media Type:
- Roll Paper
- Fanfold
- Ticket
- Film
- Synthetic Media
- Direct Thermal Paper
- Thermal Transfer Label
- Media Sensor:
- Transmissive Media Sensor
- Reflective Media Sensor
- Label Core Size: 3"
- Maximum Roll Diameter: 8"
Other
- Platform Supported: PC
- Certifications & Standards:
- FCC-B
- UL
- CSA
- ETSI EN 300 220
- CE
- Additional Information:
- Online Data Validation(ODV)
- Sensing Methods:
- Transmissive
- Reflective
Power Description
- Input Voltage:
- 110 V AC
- 220 V AC
Memory
- Standard Memory: 32 MB
- Memory Technology: DRAM
- Flash Memory: 8 MB
Warranty
- Limited Warranty: 1 Year
