Symbol LS 5800 Barcode Scanner
Part #: LS5800000SNN0500 | SKU: SYM23752

Symbol Technologies introduces the LS 5800 the new standard in hands-free point-of-sale retail laser scanning. These omni-directional mini-slot scanners feature broad yet dense scan fields for unsurpassed throughput and a high first-pass read rate. The expanded working range and aggressive performance combine for fast accurate scanning with minimal operator effort. The result is quicker more productive check-out operations and happier customers. Symbol's LS 5800 is the in-counter scanner that saves you time and energy - pass items over the scan window and the improved optics find the barcode and scan it instantly.

Symbol LS 5800 Barcode Scanner

Part Details: LS 5800, In-Counter scanner, STD, SS, SAP.

Need a different version of the Symbol LS 5800 Barcode Scanner? View all 5 configurations

Additional Information

Manufacturer	Symbol
Model Name	LS 5800
Scanner Capability	1D

Symbol LS 5800 Specs (pdf)

Technical Information

Barcode Dimension: 1D
Scan Pattern: Omni-directional
Scan Rate: 1600 scan/s
Connectivity Technology: Cable
Light Source: Laser
Barcode Symbology Supported:
- Code 39
- Code 128
- EAN/UCC 128
- Interleaved 2 of 5
- Codabar
- UPC/EAN/JAN
- Code 39
- Code 128
- EAN/UCC 128
- Interleaved 2 of 5
- Codabar
- UPC/EAN/JAN
Depth of Field: 0 mil - 6"@ - 100% UPC

General Information

Product Type: In-counter Barcode Scanner
Brand Name: Motorola
Manufacturer: Motorola, Inc
Product Model: LS 5800
Product Name: Symbol LS 5800 Barcode Reader
Product Line: Symbol

Physical Characteristics

Height: 3"
Width: 6"
Depth: 6"
Weight (Approximate): 2.40 lb

Interfaces/Ports

Host Interface: Multi-interface

Other

Certifications & Standards:
- Product Safety:
- UL
- CSA
- IEC/European Union Requirement
- Laser Safety:
- U.S. CDRH CLASS IIA
- US DHHS 21 CFR 1040.10 Subchapter J
- European Union KLASSE EINS (CLASS ONE)
- IEC285-1:1993/EN60825
- EMI/RFI/EMC:
- U.S. FCC Part 15 Subpart B Class A Limits
- Canada
- RSS.210 Class A Limits
- International/European Union: EMC Directive 89/336/EEC
Additional Information:
- Supported Interfaces:
- OCIASerialIBM 468X/469XKeyboard Wedge

Power Description

Input Voltage: 5 V DC
