Additional Information
| Included Features | microSD Flash Memory Slot |
|---|---|
| Interface Options | Serial (RS-232), USB |
| Manufacturer | TSC |
| Max Roll Outer Diameter | 5 |
| Model Name | TTP-323 |
| Print Resolution | 300 dpi |
| Printer Type | Desktop |
| Printing Technology | Thermal Transfer |
| Ribbon Core Size | 0.5 inch |
TSC TTP-323 Specs
Technical Information
- Maximum Mono Print Speed: 3 in/s
- Maximum Print Resolution: 300 dpi
- Print Color: Monochrome
- Maximum Print Width: 2.13"
- Recommended Use: Label Print
- Features: Real Time Clock
- Barcode Symbology Supported:
- Code 39
- Code 93
- Code 128 UCC
- Code 128-A
- Code 128-B
- Code 128-C
- Codabar
- Interleaved 2 of 5
- EAN-8
- EAN-13
- EAN 128
- UPC-A
- UPC-E
- UPC-5 Digits Add-on
- UPC -2 Digits Add-on
- MSI
- Plessey
- POSTNET
- China Post
- GS1 DataBar
- Code 11
- PDF-417
- Maxi Code
- Data Matrix
- QR Code
- Aztec Code
General Information
- Product Type: Direct Thermal/Thermal Transfer Printer
- Brand Name: TSC Auto ID
- Manufacturer: TSC Auto ID Technology Co., Ltd
- Product Model: TTP-323
- Product Name: TTP-323 Label Printer
Physical Characteristics
- Height: 7"
- Width: 5.5"
- Depth: 9.5"
- Form Factor: Desktop
- Weight (Approximate): 5.40 lb
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
Media Types & Handling
- Maximum Label Width: 92.9 mil
- Maximum Label Length: 40"
- Media Type:
- Label
- Tag
- Gap
- Black Mark
- Notch
- Wristband
- Die-cut Label
- Fanfold
- Notched
- Media Thickness: 7.48 mil
- Media Sensor:
- Cover Open Sensor
- Transmissive Media Sensor
- Reflective Media Sensor
- Out Of Ribbon Sensor
- Label Core Size: 1.50"
- Ribbon Core Size: 0.50"
- Maximum Roll Diameter: 5"
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority:
- RoHS
- WEEE
- Platform Supported: PC
- Certifications & Standards:
- FCC Class B
- CE Class B
- C-Tick Class B
- UL
- CUL
- TÜV/Safety
- CCC
Memory
- Standard Memory: 8 MB
- Memory Card Slot: Yes
- Memory Card Supported: microSD
- Memory Technology: DRAM
- Flash Memory: 4 MB
Power Description
- Input Voltage: 24 V DC
- Power Source: Power Adapter
Warranty
- Limited Warranty: 2 Year
Display & Graphics
- Display Screen Type: LCD
Fonts & Emulation
- Language Emulation: TSPL-EZ
